A New well Pattern for Enhancing Waterflood Performance of Ultra-Low Permeability Reservoir in Changqing Oilfield

Abstract:

Because the development of ultra-low permeability reservoir is relative to fracture system, suitable well pattern arrangement is very significant for effective flooding management. There were three kinds of well pattern used to waterflood in Changqing oilfield: square inverted nine-spot, rhombus inverted nine-spot and rectangular five-spot pattern, according to the degree of fracture growth. In view of the defects of these well patterns in the development of ultra-low permeability reservoirs, a new well spacing concept is developed. Numerical simulations are carried out to illustrate the adaptability and strong points of this new well pattern. For this well pattern, on the one hand, the distance between producers and injectors along the fracture direction is widened and thus massive fracturing can be conducted to enhance oil productivity and water injection, and on the other hand, a high producer/injector ratio ensures high oil recovery rate in early stage. Besides, this new well pattern has a great ability of adjustment. Field application showed a remarkably well producing performance.

• Periodical: Applied Mechanics and Materials (Volume 318)
• Pages: 501-506
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.318.501
• Online since: May 2013
• Authors: Zhang Zhang, Shun Li He, Hai Yong Zhang
• Keywords: Modified Rhombus well Pattern, Natural Fractures, Oil Recovery Rate, Suitability, Ultra-Low Permeability Reservoir

References

[1] L.B. Zeng, Z.X.Li, C.En.Shi, et al, Characteristics and causes of fractures in upper triassic Yanchang group of ultra-low permeability Sandstone Reservoir in Ordos Basin, J. ACTA GEOLOGICA SINICA 81 (2007) 174-180.

[2] X.G. Zhou, L.Y. Zhang, C.J. Huang, et al, Quantitative forecast of distribution Law and characteristics of tectonic fractures in low permeability reservoir of Yanhewan exploration area, J. ACTA PETROCA SINICA 23 (2009) 195-200.

[3] D.T. Snow, Anisotropic permeability of fractured media, J. Water Resources Research 5 (1969) 1273-1289.

[4] W.Rose, Permeabiltiy anisotropy in low permeability formations, in SPE Unconventional Gas Recovery Symposium, 1982.

[5] Y.H. Ding, Z.Chen, B.Zeng, et al, The development well-Pattern of low and anisotropic permeability reservoirs, J. ACTA PETROL EI SINICA 23 (2002) 64-67.

[6] Z.L. Liu, Z.S. Wei, W.L. Chen, et al, Optimal flooding patterns in fractured low-permeability sandstone reservoir, J. Petroleum Exploration and Development 30 (2003) 85-88.

[7] G.L. Chen, C.X. Liang, Z.L. Liu, et al, Optimization of the flooding pattern in reservoirs with obvious directions of fracture and sand body, J. Petroleum Exploration and Development 31 (2004) 112-115.

[8] L.Li, B.Y.Ji, B.W. Cui, Infilling method of well pattern suitable to imbibition oil recovery for fractured and extra lower permeability oil reservoirs, in International Oil & Gas Conference and Exhibition in China, 2006.

DOI: 10.2118/104430-ms

[9] Y.Li, R.P. Wang, C.L.Li, Vectorial well arrangement in anisotropic reservoirs, J. Petroleum Exploration and Development 33 (2006) 225-227.

[10] C.En.Shi, X.F.Qu, Q.H. Lei, et al, The optimization of well pattern in ultralow-permeability reservoir, in International Oil & Gas Conference and Exhibition in China, 2006.

[11] P.Hui, Y.Y. Dai, Field practice of improvement of waterflooding effect for a naturally fractured low-permeability field, in SPE Western Regional and Pacific Section AAPG Joint Meeting, 2008.

DOI: 10.2118/114200-ms

[12] P.Hui, Y.X.Li, Reservoir simulation study on improvement of waterflooding effect for a naturally fractured low permeability field in DaQing, China: a successful case, in SPE Middle East Oil and Gas Show and Conference, 2009.

DOI: 10.2118/118836-ms

[13] M.Oda, An equivalent continuum model for coupled stress and fluid flow analysis in jointed rock masses, J. Water Resources Research 2 (1986) 1845-1856.

DOI: 10.1029/wr022i013p01845

[14] J.C.S. Long, J.S. Remer, C.R. Wilson, et al, Porous media equivalents for networks of discontinuous fractures, J. Water Resources Research 18 (1982) 645-658

DOI: 10.1029/wr018i003p00645

[15] X.Q. Ran, J.Y. Zhao, S.H.Li, et al, New methods about the productivity contribution evaluation and development features of natural fractures in ultra-low permeability reservoir, in International Oil and Gas Conference and Exhibition in China, 2010.

DOI: 10.2118/131911-ms
