Research on Inverter Loss in Different Control Strategies of Electric Vehicle

Abstract:

An approximation method for calculating inverter power loss is proposed for SVPWM widely used in the electric vehicle drive system. Losses in the different vector sectors are calculated separately according to the characteristics and parameters of the IGBT in the loss approximation method. After that, for id=0 control and MTPA control of the permanent magnet synchronous motor, the power losses are calculated respectively and compared. This approximation method provides a theoretical basis for the selection of the appropriate power module and the rational design of cooling devices for the inverter

• Periodical: Applied Mechanics and Materials (Volumes 321-324)
• Pages: 1507-1513
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.321-324.1507
• Online since: June 2013
• Authors: Yuan Zhu, Gen Sheng Li, Zhi Hong Wu
• Keywords: Efficiency, Inverter, Loss, Permanent Magnet Synchronous Motor, SVPWM

References

[1] MAO Peng, XIE Shao-jun, XU Ze-gang. Switching Transients Model and Loss Analysis of IGBT Module[J]. Proceedings of the CSEE, 2010,30 (15):40-47

[2] HONG Feng, SHAN Ren-zhong, WANG Hui-zhen, YAN Yang-guang. Analysis and Calculation of Inverter Power Loss [J]. Proceedings of the CSEE, 2008,28 (15):72-78

[3] Xie Qinlan, Chen Hong. Losses Calculating of IGBT's in PWM Inverters [J]. Journal of South-Central University for Nationalities (Nat. Sci. Edition). 2003,22 (1):39-41

[4] A. M. Bazzi,P. T. Krein,J. W. Kimball. IGBT and Diode Loss Estimation Under Hysteresis Switching[J]. Power Electronics, IEEE Transactions on, 2012,27 (3):1044-1048

DOI: 10.1109/tpel.2011.2164267

[5] P. Ranstad, H. P. Nee. On Dynamic Effects Influencing IGBT Losses in Soft-Switching Converters. Power Electronics[J], IEEE Transactions on, 2011,26 (1):260-271

DOI: 10.1109/tpel.2010.2055581

[6] XIONG Yan, SHEN Yan-qun, JIANG Jian, HE Xiang-ning. Study on Loss Calculation and Model for IGBT [J]. Power Supply Technologies and Applications,2006,9 (5):55-60

[7] Zhang Mingyuan, Shen Jianqing, Li Weichao, Geng Shiguang, Tong Zhengjun. Calculation Method of a Fast Power Loss for IGBT Modules [J]. Marine Electric & Electronic Engineering, 2009,29 (1):33-36

[8] YAN Daxin, YU Yannan, JIANG Hua. Research on Simulation of SVPWM Three － phase Voltage Inverter [J]. System Simulation Technology, 2012,8 (1):56-61

[9] D. Grahame Holmes,Thomas A. Lipo. Pulse Width Modulation for Power Converters: Principles and Practice [M]. Wiley-IEEE Press.(2003)

[10] Huang Shoudao,Chen Ziqiang,Huang Keyuan.Maximum torque per ampere and flux-weakening control for PMSM based on curve fitting[C]. Vehicle Power and Propulsion Conference (VPPC), 2010 IEEE, 1-3 Sept. 2010:1-5

DOI: 10.1109/vppc.2010.5729024

[11] GUO Qingding,CHEN Qifei,LIU Chunfang. Efficiency optimization control of PMSM based on maximum ratio of torque to current [J]. Journal of Shenyang University of Technology, 2008,30 (1):1-5

[12] Infineon Technologies. IGBT-Module FS800R07A2E3. http://www.infineon.com/dgdl/DS_FS800R07 A2E3_3_0.PDF?folderId=db3a30431a5c32f2011a72c7daa47094&fileId=db3a304320d39d590121b0581fc82d8d. (2012)
