QoS Oriented Traffic Modeling of Mobile POS Service in Cellular Network

Abstract:

The market potential of mobile point of sale (POS) service is attractive to the mobile network operators, while the traffic challenges caused by heavy traffic is becoming a critical issue to the operators. In order to guarantee the Quality of Service (QoS) and make best use of the existing network, it is important to model the traffic of mobile POS service. A tree-structured modeling method is presented in the paper, which can be used to model the traffic of mobile POS service as well as other interactive M2M services, such as remote medical services. The modeling method is a combination of the layered modeling method used in traditional H2H communications and the transaction tree modeling method used in bank trade. As another main point, a specific traffic model of mobile POS service is given in the paper. There are five parameters in the traffic model, including request packet size, response packet size, the interval between request and response, the interval between two requests, and the transmission probability. After counting the packet length of each message, calculating the average length, analyzing the effect of difference between the actual and average length on the cellular network, we find that all the request type of mobile POS service could be simplified as the average length. Further on, a curve-fitting method is used to obtain the distribution of the intervals. All the data used in the modeling are collected from the traffic of real network. The QoS attributes assumption of mobile POS service including the maximum accessing user number, the packet loss rate and the end-to-end delay is given in the article and is validated by the simulation using the specific model of mobile POS service provided in the paper. The assumption is consistent with the simulation result, and is proved to be reasonable. The results can be used as a reference when implementing mobile POS service in cellular network.

• Periodical: Applied Mechanics and Materials (Volumes 321-324)
• Pages: 2841-2848
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.321-324.2841
• Online since: June 2013
• Authors: Rong Duo Liu, Wei Wu, Jia Dong Du, Wei Xin, Da Cheng Yang
• Keywords: Cellular Network, Machine-to-Machine, Mobile Point of Sales, Quality of Service (QoS), Traffic Model

References

[1] EnfoDesk, "Third-party payment market trend forecast 2011-2014", March,2010[2] Cao Jiguang, Evolution of IP QoS Concept, Telecomm Network Technology, July. (2004)

[3] Kunjie, Wu, "Application of GRPS based Mobile POS in finance sector", master thesis of Guizhou University, April. 2007.

[4] Hongli Niu, Bin Bo, "Application Analysis of Mobile POS system in power rate counting",  Intelligence, vol. 35, December. 2011.

[5] Jihong, Chen, "The Mobile POS system in bank ", Financial Computer of China, vol.9, September. (2005)

[6] O. Rose, "Statistical properties of MPEG video traffic and their impact on traffic modeling in ATM Systems", Institute of Computer Science University of Würzburg, Am Hubland D-97074 Würzburg, Germany

DOI: 10.1109/lcn.1995.527368

[7] The 3rd Generation Partnership Project, Technical Specification Group Radio Access Network, Feasibility Study for Orthogonal Frequency Division Multiplexing (OFDM) for UTRAN enhancement, 3GPP TS 25.892-600 v6.0.0, June (2004)

[8] D. Heyman, T.VLakshman, A.Tabatabal, et al., "Modeling Vol.3， May, 1994， p.1744 一1745

[9] A. Reyes-Lecuona, E. González-Parada, E. Casilari, J. C. Casasola, A. Díaz-Estrella, "A page-oriented WWW traffic model for wireless system simulations", Proc of 16th ITC, Edinburgh, June, 1999, pp.1271-1280

[10] Shenyan Chen, Min Cao, "Research and application of multi-association rule mining algorithm", Computer Engineering and Design, vol.31, 2010.

[11] China UnionPay Co., Ltd, Q/CUP 007-2006 "Specification for point of sale (POS) terminal"[12] Kunjie Wu, "The application of wireless POS based on GPRS in financial industry", Master's thesis of Guizhou university, (2007)

[13] ITU-T Y.1541 Network performance objectives for IP-based services 3GPP TR 23.882 Report on Technical Options and Conclusions

[14] 3rd Generation Partnership Project;Technical Specification Group Radio Access Networks;User Equipment (UE) radio transmission and reception (FDD); Techincal Specification 3GPP TS 25.101 v 3.19.0, (2006)
