A Model-Based Fault Detection Methodology for Vacuum Circuit Breaker

Abstract:

Vacuum circuit breaker becomes more and more complicated, integrated, high-speed and intellectualized. To insure vacuum circuit breaker in its good conditions, the function of fault diagnosis gets more important than before in the process of repairing. This paper is addressed a model-based fault detection methodology for vacuum circuit breaker. At first, the dynamic model of vacuum circuit breaker is built. Secondly, DTW algorithm is introduced to compute the similarity value between the test data and the theoretical data. At last, the value comparison between the similarity and the threshold concludes whether a fault has occurred or the vacuum circuit breaker has potential hazardous effects. The experimental results show that this method is effective.

• Periodical: Applied Mechanics and Materials (Volumes 321-324)
• Pages: 739-742
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.321-324.739
• Online since: June 2013
• Authors: Yu Huang Zheng
• Keywords: Dynamic Time Warping (DTW), Fault Diagnosis, Vacuum Circuit Breaker (VCB)

References

[1] B.V. Klimenko: Russian Electrical Engineering, Vol.83(2012),p.243

[2] Y. Luo, X. Duan, Z. Tian: Journal of Computational Information Systems, Vol. 8(2012),p.8707

[3] S. M. Strachan, S. D. J. McArthur, B. Stephen, J. R. McDonald and A. Campbell: IEEE Trans. on Power Delivery, Vol.22(2007), p.178

[4] R. Alexandru: Electrotehnica, Electronica, Automatica, Vol. 60(2012),p.59

[5] J. H. Mousavi: Transmission and Distribution Conference and Exposition(2008), p.1

[6] J. Zieba: FIBRES & TEXTILES in Eastern Europe, Vol.11(2003), p.85

[7] J. Y. Jang, D. K. Park and S. E. Yang: IEEE Trans. on Applied Superconductivity, Vol.20(2010), p.1151

[8] P. Rao, J. Huang and X. Hu: IEEE International Conference on Control and Automation(2009), p.185

[9] G. Song, Y. He, F. Chu and Y. Gu :Expert Systems with Applications, Vol. 34(2008), p.764

[10] S. C. Hui, A. C. M. Fong and G. Jha: Engineering Applications of Artificial Intelligence, Vol. 14(2001), p.537

[11] X. Wu, J. Chen, R. Li and F. Li: The International Journal of Advanced Manufacturing Technology, Vol. 28(2006), p.232

[12] S. K. Ong, N. An and A. Y. C. Nee: The International Journal of Advanced Manufacturing Technology, Vol. 18(2001), p.166

[13] W. Jia,Y. Peng and Z. Yang:8th International Conference Electronic Measurement and Instruments(2007), p.382

[14] Endi, M.; Elhalwagy, Y.Z.: The 2nd International Conference on Computer and Automation Engineering (2010), p.774

[15] H.Sakoe, S.Chiba:IEEE Trans. on Acoustics, Speech and Signal Processing, Vol.26(1978), p.43
