Gas Concentration Monitoring System Based on Soft Redundancy and ZigBee

Abstract:

The scheme based on soft redundancy and ZigBee is introduced due to the inadequacy of existing mine gas concentration monitoring system. The system is divided into underground and aerial parts. The gas concentration of mine working site can be tested automatically by underground part, which can transmit the data to the ground using ZigBee wireless communications technology. Two sets of identically configured PLC control system constitute the aerial part, which can meet redundancy requirements by procedures and directives. The solid technical support in mine safe operation can be provided based on the system, which improves the stability and reliability of the gas concentration monitoring.

• Periodical: Applied Mechanics and Materials (Volumes 321-324)
• Pages: 753-756
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.321-324.753
• Online since: June 2013
• Authors: Bo Huang, Kang Liu, Liang Dong Zhang
• Keywords: Gas Concentration Monitoring, Programmable Logic Controller (PLC), Soft Redundancy, ZigBee

References

[1] NI Tao. System of Gas Detecting and Alarming Based on MCU [J]. Coal Mine Machinery, 2010, 31(12): 201-204. (In Chinese)

[2] WANG Chun, LIAO Ying-hua, ZHANG Liang-dong, LIU Ming. Design of welding power source man-machine interaction system based on Proteus [J]. Electric Welding Machine, 2011, 41(9): 81-84. (In Chinese)

[3] LI Quan, NAN Xin-yuan. Application of PLC Software Redundancy in the Monitor System [J]. Mechatronics, 2011, (12): 93-96. (In Chinese)

[4] LI Fu-xiang, GUO Li-jin, LI Lu. Design of the Discarded Sodium Sewage Treatment System Based on PLC Soft-redundant Technology [J]. Automation & Instrumentation, 2011, (11): 45-48. (In Chinese)

[5] MENG Yan-jing, JIN Lu. Application of PLC Software Redundancy in Wind Generator System [J]. Control and Instruments in Chemical Industry, 2010, 37(10): 109-111. (In Chinese)
