Pilot-Induced Oscillations Prevention Using Anti-Windup Compensation in the Presence of Time-Delay

Abstract:

The paper presents a compensator design technique for systems with saturating actuators in order to recover as much as possible the performance of the unsaturated case. This anti-windup scheme is obtained using H-infinity optimization methodology. The proposed design approach allows to obtain a anti-windup controller that accounts for time-delays in the control system. Comparative result are presented for the two design methods and time simulation of the nonlinear system are used to analyze the performances of both designs. A reduced order anti-windup controller procedure is also investigated. Keywords: PIO, anti-windup, rate saturation, compensator.

• Periodical: Applied Mechanics and Materials (Volumes 325-326)
• Pages: 1262-1266
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.325-326.1262
• Online since: June 2013
• Authors: Valentin Pană
• Keywords: Anti-Windup, Compensator, PIO, Rate Saturation

References

[1] L. Forssell, and U. Nilsson, ADMIRE The Aero-Data Model In a Research Environment Version 4.0, Model Description, Report FOI-R-1624-SE, ISSN 1650-1942, Swedish Defence Research Agency, Available at www.foi.se/admire.

[2] S. L. Gatley, M. C. Turner, I. Postlethwaite, A. Kumar. A comparison of rate-limit compensation schemes for pilot-induced-oscillation avoidance, Aerospace Science and Technology 10 (2006) 37-47, Elsevier.

DOI: 10.1016/j.ast.2005.07.004

[3] K. Glover, All Optimal Hankel-Norm Approximation of Linear Multivariable System and Their -error Bounds, Int. J. Contr., vol. 39, pp.1115-1193, 1984.

DOI: 10.1080/00207178408933239

[4] K. Glover, J.C. Doyle, State-Space Formulae for All Stabilizing Controllers that Satisfy an -Norm Bound and Relations to Risk Sensitivity, Systems & Control Letters, Vol 11, pp.167-172.

DOI: 10.1016/0167-6911(88)90055-2

[5] M. Hagström, The ADMIRE Benchmark Aircraft Model, Nonlinear Analysis and Synthesis Techniques for Aircraft Control, Lecture Notes in Control and Information Sciences, 2007, Volume 365, Springerlink.

DOI: 10.1007/978-3-540-73719-3_3

[6] B.S. Liebst, M.J. Chapa, D.B. Leggett. Nonlinear Prefilter to Prevent Pilot-Induced Oscillations due to Actuator Rate Limiting , Journal of Guidance Control and Dynamics, 2002, vol.25 no.4, pp.740-747.

DOI: 10.2514/2.4941

[7] D. T. McRuer, D. H. Klyde, and T. T. Myers, Development of a Comprehensive PIO Theory, AIAA paper 96-3433, (1996), pp.581-597.

[8] V. Pană, A. M. Stoica. Robust Analysis Approach for Prediction of Pilot Induced Oscillations, 14th International Conference on System Theory and Control SINTES 2010.

[9] L. Rundqwist, R. Hillgren. Phase compensation of rate limiters in JAS 39 Gripen, AIAA Atmospheric Flight Mechanics Conference, San Diego, CA, July 29-31, 1996.

DOI: 10.2514/6.1996-3368

[10] J. Sofrony, M. C. Turner, I. Postlethwaite, O. Brieger, D. Leissling, Anti-windup synthesis for PIO avoidance in an experimental aircraft, 45th IEEE Conference on Decision and Control, 2006.

DOI: 10.1109/cdc.2006.377217

[11] S. Tarbouriech, M. C. Turner. Anti-windup design: an overview of some recent advances and open problems, IET Control Theory Appl., 2009, Vol 3, No. 1, pp.1-19.

DOI: 10.1049/iet-cta:20070435
