Stress Analysis of Photo-Elastic Orthotropic Composite Material and Measurement Fringe Value of Shear Material

Abstract:

Based on the analysis characteristics of orthotropic composite material under antisymmetric force, a new measurement method is established which can independently measure the fringe value of optical shear orthotropic material by pure-shear experiment. Two orthotropic photo-elastic composite material beams with rectangular cross-section which fiber orientation is 0 °, 90 ° respectively are loaded anti-symmetric force, so that the anti-symmetric section is in a pure shear stress state. The fringe value of orthotropic photo-elastic shear composite material is measured . The results agree with three stripe specimens tensile experiment.

• Periodical: Applied Mechanics and Materials (Volume 330)
• Pages: 12-17
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.330.12
• Online since: June 2013
• Authors: Yun Jiang, Hua Dong Zhang, De Ben Hu, Xiao Chun Fan
• Keywords: Anti-Symmetric Four-Point Bending, Composite Material, Orthotropic Photo-Elasticity, Shear Material Fringe Value

References

[1] Sampon Robert C, A Stress –Optic Law for Photoelastic Analysis of Orthotropic Composites. Exp. Meach, Vol. 10-2(1970), pp.210-215

[2] Xu Luwen.Stress analysis of photoelastic composite circular disk under diametral compression and determination of material fringe values. Journal of Experimental Mechanics，Vol. 1-2 (1986), pp.304-308

[3] Liu Xili, Wang Bingquan. Composite material mechanic. China Building Industry Press, Beijing (1984), in press.

[4] Yang Rongsheng. Orthotropic composite materials research stress optical theorem. Journal of Composite Materials. Vol.1-4(1986), p.57~61

[5] Xu Luwen, Wang Yubing, Chen Peiwen. Mechanical analysis of photoelastic model material. Journal of Applied Mechanics. Vol.3-2, (1986), p.30~36
