Truss Structure Health Monitoring Based on Electromechanical Impedance Method

Abstract:

Truss structure is widely used in civil engineering applications for its advantages of easy transportation, convenient assembly and uniform loading. However, it is difficult to achieve real-time health monitoring because of connection diversity and complexity of truss structures. As a novel structural health monitoring technique, electro-mechanical impedance method could monitor the health state of one structure by measuring the spectra of impedance or admittance of the piezoelectric elements, which are bonded on the surface of this structure. This approach has the advantages of nonparametric model analysis, easy sensor installation and high local sensitivity, especially in sensitive frequency range. The damage information, which is tested and recorded by using electromechanical impedance method, could convert into intuitive results through neural network because of its good ability for nonlinear mapping. In this paper, a three-layer assembly truss structure was chosen as experimental object, piezoelectric elements were bonded on structure joints to measure structural impedance spectra, the change of these structural impedance spectra was tested and recorded under high frequency excitations when different truss bars were loosed, and then, one back-propagation (BP) neural network was built and trained by this damage information, which were treated as input samples. These results show that the sensitivity of impedance method is not the same to different frequency range and trained neural network could quickly identify loosen truss bars.

• Periodical: Applied Mechanics and Materials (Volume 330)
• Pages: 357-363
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.330.357
• Online since: June 2013
• Authors: Cun Fu He, Xiao Ming Cai, Shen Yang, Zeng Hua Liu, Bin Wu
• Keywords: Electromechanical Impedance, Neural Network (NN), Spectrum, Structural Health Monitoring (SHM), Truss

References

[1] F. Sun, Z. Chaudhry,C. Liang and C. Rogers, "Truss structure integrity identification using PZT sensor-actuator," J. Intell. Mater. Syst. Struct., Vol. 6, pp.134-139, January. 1995.

DOI: 10.1177/1045389x9500600117

[2] X. Liu and Z. Jiang, "Design of a PZT patch for measuring longitudinal mode impedance in the assessment of truss structure damage," Smart Mater Struct, Vol. 18, pp.125017-8, October. 2009.

DOI: 10.1088/0964-1726/18/12/125017

[3] D. Mascarenas, M. Todd, G. Park and C. Farrar, "Development of an impedance-based wireless sensor node for structural health monitoring," Smart Mater Struct, Vol. 16, pp.2137-2145, October. 2007.

DOI: 10.1088/0964-1726/16/6/016

[4] B. Wu, X. Tong, Z. Liu and C. He, "Experimental study of structural health monitoring for pipeline flange based on electromechanical impedance," Journal of Experimental Mechanics, Vol. 25, pp.516-521, October. 2010.(in Chinese)

[5] V. Lopes, G. Park, H. Cudney and D. Inman, "Impedance-based structural health monitoring with artificial neural networks," J. Intell. Mater. Syst. Struct. , vol. 11, pp.204-214, March. 2000.

DOI: 10.1177/104538900772664477

[6] A. Zagrai and V. Giurgiutiu, "Health monitoring of aging aerospace structures using the electro-mechanical impedance method," Pro. SPIE 4702. Smart Nondestructive Evaluation for Health Monitoring of Structural and Biological Systems, SPIE Press, Apr. 2003, pp.289-300.

DOI: 10.1117/12.469885

[7] W. Yan, L. Yuan, "Damage detection in structural systems using a hybrid method integrating EMI with ANN," Proc. IEEE Asia-Pacific. Power and Energy Engineering Conference (APPEEC), IEEE Press, March. 2010, pp.1-4.

DOI: 10.1109/APPEEC.2010.5448696

[8] J. Min, S. Park, C. Yun, C. Lee and C. Lee, "Impedance-based structural health monitoring incorporating neural network technique for identification of damage type and severity," Eng. Struct, vol. 39, pp.210-220, March 2012.

DOI: 10.1016/j.engstruct.2012.01.012

[9] C. Liang, F. Sun and C. Rogers, "Coupled electro-mechanical analysis of adaptive material systems - Determination of the actuator power consumption and system energy transfer," J. Intell. Mater. Syst. Struct., vol. 5, pp.12-20, January 1994.

DOI: 10.1177/1045389x9400500102

[10] D. Du, D. Qiu, A. Li and X. Wang, "Application of artificial neural network on structural health monitoring in civil engineering," Nondestructive Testing, vol. 26, pp.383-387, August 2004.(in Chinese)
