Numerical Analysis on Collision Process of Rigid Body and Box Girder

Abstract:

Through analyzing the real collision process of a steel plate rolling sliding off a lorry and box girder flange of an overpass, the damage degree of box girder may be known, and in this article the collision process is also simulated by means of finite element method so that it may be obtained how the damaged girder collapses and the cracks propagate. Furthermore, the dynamic characteristics are studied during the collision process and the reliability of overpass section collision is analyzed from the angle of energy transfer and dissipation.

• Periodical: Applied Mechanics and Materials (Volume 330)
• Pages: 331-337
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.330.331
• Online since: June 2013
• Authors: Rui Xiong, Jun Feng Shi, Qun Hui An, Tian Qing Yu
• Keywords: ANSYS/LSDYNA, Crack, Damage, Numerical Analysis, Penetration

References

[1] Jiang Jianqiong, Lu Xinzheng, Ye Lieping, "Finite element analysis of concrete structures"Tsing hua,in press.

[2] T.J. Holmquist, Dr.G.R. Johnson, Dr.W.H. Cook, "A computational constitutive model for concrete subjected to large strains, high strain rates, and high pressures," Fourteenth International Symposium on Ballistics, Quebec City, Canada, 1993,9.

DOI: 10.1115/1.4004326

[3] LS-DYNA Keyword user's manual Volume II. Livermore Software Technology Corporation(LSTC), 2007,5:418.

[4] Cai Qing-yu, Cui Wei-feng, Xiang Dong, Zeng Xinwu, "Simulation of Concrete Penetrated by Rigid Projectile with Coupled FE-SPH Methods", Journal of national university of defense technology, vol. 25, No.6 2003. 87-90.
