Buried Crack Detection in Aircraft Multi-Layer Structure Based on Pulsed Eddy Current

Abstract:

The fatigue cracks of key parts, as one of the main damages of multilayer structure in aircraft, are important objects for aircraft structural health monitoring. Conventional electromagnetic testing which uses sinusoidal signal is high sensitive to surface cracks, but it is typically difficult to measure or predict embedding cracks. A novel electromagnetic detection technique is proposed in this paper, and dual polarity low-frequency pulse is used to excite the coil. A time-domain analysis method called time-slice is utilized to obtain the transient amplitude matrix from array signal. Good results have been presented by such dynamic imaging of simulating buried cracks in multi-layer riveted structure. Experimental results show that the new electromagnetic testing has the advantages of hidden defects detection and rapid detection, and it can effectively detect buried defects in multilayer structures of aircraft, and determine damage position.

• Periodical: Applied Mechanics and Materials (Volume 330)
• Pages: 536-541
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.330.536
• Online since: June 2013
• Authors: Sheng Lai, Hu Chen, Yue Wen Fu
• Keywords: Array, Dual Polarity Low-Frequency Pulse Excitation, Imaging Scan, Time Slice

References

[1] W.D. Rummel and J.R. Bowler, "Integrated Quantitative Nondestructive Evalution (NDE) and Reliability Assessment of Aging Aircraft Structures", Final Report for the United States Air Force Office of Scientific Research, April, 2001.

[2] J.C. Moulder and J.A. Bieber, "Scanned pulsed eddy current instrument for nondestructive inspection of aging aircraft", SPIE, 1996, p.2–13.

DOI: 10.1117/12.259077

[3] J.C. Moulder and J.A. Bieber, "Pulsed eddy current measurements of corrosion and cracking in aging aircraft", Materials Research Society Symposium Proceedings of Nondestructive Characterization of Materials in Aging Systems, vol.503, , 1998, p.263–268.

DOI: 10.1557/proc-503-263

[4] Yuri Plotnikov and GE Global Research, "Pulsed Eddy Current Technology and Aerospace Applications", GE Inspection Technologies, 2005, p.1–23.

[5] G.Y. Tian, A.Sophian and D.Taylor, "Multiple sensors on pulsed eddy current detection for 3-D subsurface crack assessment", IEEE SENSORS, vol.5,NO.1,2005, p.90–96.

DOI: 10.1109/jsen.2004.839129

[6] Haiyan Sun and Raza Ali, "Enhanced flaw detection using an eddy current probe with a linear array of hall sensors", Review of Quantitative Nondestructive Evaluation, vol.24, 2005, p.516–522.

DOI: 10.1063/1.1916719

[7] M.A. Plonus, "Applied Electromagnetics", New York: McGraw Hill, 1978.

[8] J.A. Bieber and J.C. Moulder, "Time-Gating of Pulsed Eddy Current Signals for Defect Characterization and Discrimination in Aircraft Lap-Joints", Review of Progress in Quantitative Nondestructive Evaluation, vol.16, 1997, p.1915–1921.

DOI: 10.1007/978-1-4615-5947-4_250
