Ultra High Pressure Control Technology on Small Cavity

Abstract:

Based on the current key problem of the ultra high pressure control technology on the small cavity, an analysis method of the ultra high pressure control was put forward on 500ml small cavity. The mathematical model was derived on pressure-volume change of the small cavity. A pressure control system was set up on the small cavity according to the model. Control program was done using labview software, test process was completed automatically, test data was displayed in real time and the output data and report form was received. The test results show that the system have achieved the function of a increasing ultra pressure. The capacity of system increasing pressure is up to 150Mpa, controlling pressure accuracy up to 0.31% and the holding pressure accuracy up to 0.48%.

• Periodical: Applied Mechanics and Materials (Volume 331)
• Pages: 376-380
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.331.376
• Online since: July 2013
• Authors: Chun Min Shang, Dong Mei Zhang, Jing Feng Fan
• Keywords: Control Pressure Precision, Hydromechanics, Small Cavity, Ultra High Pressure

References

[1] Qinghua Gong, Yun Piao, Xiaodong Wang, Research on hydraulic system ultra high pressure technology[J]. Coastal Enterprises and Science & Technology, 2007,1:81–83(in Chinese).

[2] Liandong Wang, Wei Zhang, Jia Cheng, et al. Development of a kind of ultrahigh pressure integration device for hydro-bulging in the common press[J].China Mechanical Engineering, 2007, 18(21):2624-1627(in Chinese).

[3] Ji Hong, Fu Xin,Yang Huayong et al. Study on the obtainable maximum pressure in hydraulic pressure control valve [J] China Mechanical Engineering, 2003,14 (14): 1227–1230(in Chinese).

[4] Mengting Zhang, Yong Zhang. Status of foreign downhole safety valve technology [J]. China Petroleum Machinery, 2008,36 (7): 81–84(in Chinese).

[5] Changyou Li,Baoquan Sun Shexia Dong, et al. Development of model SC35-120A downhole safety valve[J]. China Petroleum Machinery, 2005, 33 (1): 43–44(in Chinese).

[6] Haijuan Chang, Liping Pang. Study on Pressure Control Strategy of High-altitude Multi-Environmental Parameter Simulation Cabin System [J]. Acta Armamentarii, 2008,29 (11): 1405–1408(in Chinese).

[7] Xing Fu, Mengchao Li, Xiaodong Hu, et al. Application of fuzzy control in the hydraulic control system with big-load and high precision[J]. Journal of Tianjin University, 2004,37 (8): 750–752(in Chinese).

[8] Chuanhai Zhao. Several important formula of hydrostatic test in long pipeline. Oil And Gas Field Surface Engineering [J] 2007,26 (3): 11–13(in Chinese).

[9] Liping Zhang, Quick reference manual of hydraulic and pneumatic technology [M] Beijing: Chemical Industry Press .2006:95–98(in Chinese).
