PC104 Interface Recommended for High Speed Data Acquisition Systems

Abstract:

The interface presented in this paper performs a synchronized sampling of all eight common-mode or differential analog inputs with a high sampling rate. This is a low cost interface, entirely controlled by the PC104 CPU. The paper is focused on design and operation aspects of the synchronized analog-to-digital conversion module. This interface is recommended for high speed data acquisition systems and finds its utility in energetic systems, for monitoring the power quality and for recording different specific transient events. Some programmable electronic modules which perform analog and digital signal acquisition in energetic systems already contain a PC104 interface with synchronized sampling of analog inputs; some experimental results are also presented in this paper.

• Periodical: Applied Mechanics and Materials (Volume 332)
• Pages: 119-123
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.332.119
• Online since: July 2013
• Authors: Dorina Purcaru, Anca Purcaru
• Keywords: Analog-To-Digital Conversion, Embedded System, Interface, Synchronized Sampling

References

[1] P. Petrovic and M. Stevanovic, Digital processing of synchronously sampled AC signals in the presence of interharmonics and subharmonics, Volume 56, No. 6, p.2584–2598 of IEEE Trans. Instrum. Meas. (2007).

DOI: 10.1109/tim.2007.908150

[2] I. Purcaru, D. Purcaru, C. Gordan and M. Niculescu, in: Digital equipment for the implementation of complex protection functions, Volume 3, No. 1, p.171–174 of Journal of Electrical and Electronics Engineering, University of Oradea Publisher (2010).

[3] D. Purcaru, A. Purcaru, C. Rusu and M. Căpăţînă, in: Electronic Equipment for Monitoring and Recording Analog and Digital Inputs, Proceedings of The 14th International Conference on System Theory and Control, pp.421-426, Sinaia, Romania (2010).

[4] D. Purcaru, A. Purcaru, C. Gordan and R. Reiz, in: Robust and Low Cost PC104 Interface with Synchronized Sampling of Analog Inputs: Hardware Solution, Proceedings of 2010 International Conference on Mechanical Engineer, Robotics and Aerospace (IEEE Catalog Number: CFP1057L-ART), pp.250-254, Bucharest, Romania (2010).

DOI: 10.4028/www.scientific.net/amm.325-326.926

[5] Information on http://www.partsprocurement.com/manufacturer/Philips-Semiconductors.asp

[6] Information on http://www.jkmicro.com/fn2969.pdf

[7] Information on http://www.ajile.com/aJ-pc104_datasheet.htm

[8] Information on http://www.datasheetcatalog.org/datasheet/intersil/fn2970.pdf

[9] Information on http://www.datasheetcatalog.org/datasheet/lineartechnology/18645f.pdf

[10] Information on http://www.nxp.com/documents/data_sheet/74HC_HCT573.pdf
