On the Choice of Shape Functions of Unsymmetrical Elastic Rotors

Abstract:

In this paper the effects of rotordynamics under the aspect of the choice of shape functions are discussed. For this purpose a rotor system which consists of a slim shaft and two rigid disks is modeled using the Projection Equation. The shaft is assumed as an elastic Euler-Bernoulli beam, supported by two bearings modeled as radial spring systems. The rotor is driven by a permanent-magnet synchronous motor whose torque is transmitted with a spur gear pair next to one of the bearings. A Ritz approach is used to separate the elastic displacements in position and time, thereby different shape functions are evaluated. Approximated eigenfunctions are computed and used as shape functions as well. For validation, the eigenfrequencies are compared with semi-analytical ones, calculated with the Transfer-Matrix-Method and experimental results. The insights obtained from this work should make it easier to choose the appropriate shape functions for such problems.

• Periodical: Applied Mechanics and Materials (Volume 332)
• Pages: 325-330
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.332.325
• Online since: July 2013
• Authors: Herbert Parzer, Hubert Gattringer, Stefan Hubinger
• Keywords: Elastic Multibody System, Projection Equation, Rotordynamics, Shape Functions

References

[1] Bremer, H.: Elastic Multibody Dynamics: A Direct Ritz Approach. Springer-Verlag GmbH, 2008. – ISBN 978–1–4020–8679–3

[2] Gattringer, H.: Starr-elastische Robotersysteme: Theorie und Anwendungen. Springer Berlin Heidelberg, 2011. – 276 S. – ISBN 978–3–642–22827–8

DOI: 10.1007/978-3-642-22828-5

[3] Gasch, R.; Nordmann, R.; Pfützer, H.: Rotordynamik. Springer, 2005 ISBN 3-540-41240-9

[4] Hubinger, S.: Ein Beitrag zur semi-analytischen Berechnung von Kontinuumsschwingungen. PhD Thesis, Johannes Kepler University Linz, (2012)

[5] Hubinger S., Gattringer H., Bremer H., Mayrhofer K.: Acceleration of Unbalanced Rotors. In: Proceedings of MATHMOD 2012 Vienna, 2,012

DOI: 10.3182/20120215-3-at-3016.00205

[6] Irschik, H., Nader, M., Stangl, M. and von Garssen, H.-G.: A floating-frame-of-reference formulation for deformable rotors using the properties of free elastic vibration modes, Proc. ASME 2009 International Design Engineering Technical Conferences & Computers and Information Conference IDETC/CIE 2009, San Diego, (2009)

DOI: 10.1115/detc2009-86660

[7] Irschik, H., Nader, M., Stangl, M. and von Garssen, H.-G.: Nonlinear Vibrations of Flexible High-Speed Rotors Supported by Visco-Elastic Bearings Proc. of the 8th IFToMM International Conference on Rotordynamics, KIST, Seoul, (2010)

[8] Parzer, H.: Elastische Modellierung eines Rotorsystems. Master Thesis, Johannes Kepler University Linz, (2012)
