Solid-Liquid Two-Phase Flow Image Reconstruction in Microchannel Based on Tikhonov Regularization Method

Abstract:

Electrical resistance tomography (ERT) has been used as an alternative technique to monitor two-phase flow because of its high temporal resolution for monitoring fast transient processes. However the image reconstruction image with ERT in microchannel suffers from poor quality because of the interference of contact resistance. This paper aims at the solid-liquid two phase flow visualization in the cross-sections of a novel microchannel based on the ERT technique. Preliminary experimental results reveal that ERT image reconstruction technique base on Agilent data acquisition system can effectively detect the particle distribution in the microchannel.

• Periodical: Applied Mechanics and Materials (Volumes 333-335)
• Pages: 1013-1019
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.333-335.1013
• Online since: July 2013
• Authors: Yong Hong Liu, Na Wang, Hai Yan Sun, Wei Chen
• Keywords: Agilent Instrument, ERT, Image Reconstruction, Micro-Channel, Two-Phase Flow

References

[1] Kikutani Y, Hisamoto H, Tokeshi M, et al, Micro wet analysis system using multi-phase laminar flows in three-dimensional microchannel network, Lab Chip, vol. 4, pp.328-332, (2004).

DOI: 10.1039/b400233d

[2] Choi J. E, Takei M, Doh D. H, Fabrication of Microchannel with 60 Electrodes and Resistance Measurement, Flow measurement and instrumentation, vol. 61, pp.2733-2738, (2010).

DOI: 10.1016/j.flowmeasinst.2010.03.006

[3] Reddy V, Zahn J. D, Interfacial stabilization of organic–aqueous two-phase microflows for a miniaturized DNA extraction module, Colloid Interf. Sci, vol. 286, p.158–165, (2005).

DOI: 10.1016/j.jcis.2004.12.052

[4] Shui L. L, Eijkel Jan C. T, Albert Vandenberg, Multiphase flow in micro- and nanochannels, Sensors and Actuators, vol. 121, p.263–276, (2007).

DOI: 10.1016/j.snb.2006.09.040

[5] Kaban'kov O. N, Sevast'yanov A. P, Two-phase flows: a review, Heat Transfer, vol. 31, p.103–122. (2000).

[6] Doku G. N, Verboom W, Reinhoudt D. N, On-microchip multiphase chemistry—a review of microreactor design principles and reagent contacting modes, Tetrahedron. Vol. 61, p.2733–2742, (2005).

DOI: 10.1016/j.tet.2005.01.028

[7] Tegenfeldt J. O, Prinz C, Cao H, Micro- and nanofluidics for DNA analysis, Anal. Bioanal. Chem, vol. 378, p.1678–1692, 2004.

[8] Ichiyanagi M, Sasaki S, Sato Y, Micro-PIV/LIF measurements on electrokinetically-driven flow in surface modified microchannels, Journal of Micromechanics and Microengineering, vol. 19, pp.1-9, (2009).

DOI: 10.1088/0960-1317/19/4/045021

[9] Ricard F, Brechtelsbauer C, Xu X. Y, Monitoring of Multiphase Pharmaceutical Processes Using Electrical Resistance Tomography, Chemical Engineering Research and Design, vol. 83, pp.794-805, (2005).

DOI: 10.1205/cherd.04324

[10] Sung Quek, Stephan Mohr, Nick Goddard, Peter Fielden and Trevor York. Miniature Electrical Tomography for MicroFluidic Systems, WCIPT6. pp.1320-1326, (2010).

[11] C.J. Grootveld, A. Segal, Regularized modified Newton–Raphson technique applied to electrical impedance tomography, Int. J. Imag. Syst. Technol., vol. 9, p.60–65, (1998).

DOI: 10.1002/(sici)1098-1098(1998)9:1<60::aid-ima8>3.0.co;2-p

[12] M. Wang, Inverse solutions for electrical impedance tomography based on conjugate gradients methods, Meas. Sci. Technol. Vol. 13, p.101–117, (2002).

DOI: 10.1088/0957-0233/13/1/314

[13] W.Q. Yang, L. Peng, Image reconstruction algorithms for electrical capacitance tomography, Meas. Sci. Technol, vol. 14, p.1–13, (2003).

DOI: 10.1088/0957-0233/14/1/201

[14] A.S. Utada, E. Lorenceau, D.R. Link, P.D. Kaplan, Monodisperse double emulsions generated from a microcapillary device, Science, vol. 308, p.537–541, (2005).

DOI: 10.1126/science.1109164
