Digital Implementation and Simulation of the ZVS Control Scheme

Abstract:

Digital control algorithm common neural networks, fuzzy control, digital PID digital PID technology used widely and mature, the digital PID proportional, integral, derivative control the abbreviation. These advantages: simple in principle, applicability; little within the small range of the controlled object parameter changes on the performance indicators, a great guarantee the validity of the regulation. PID is the most successful control strategy in the analog control technology, digitized; people naturally will this control strategy is grafted onto the digital control technology. The system is digital PID.Used to implement a digital control chip has many, e.g., microcontroller, field programmable gate arrays (FPGAs), digital signal processor (DSP) and the microcontroller (ARM). SCM is the first large-scale application of the controller, but due to the speed of operation and the median can not meet the growing industrial control requirements. .
