A Peak Identification Method of Vibration Signal on Diesel Engine Cylinder Head in the Absence of TDC Signal

Abstract:

This paper studied the time-domain waveform characteristics of diesel engine cylinder head vibration. The relative relationship between the various explosions of diesel engine were analyzed and compared. Seven criteria were proposed under which to achieve the time domain waveform peak identification in the absence of TDC signal. According to the criteria computer algorithms for the time domain waveform peak identification were given. The method can reduce the vibration diagnosis system using request such as can achieve misfire fault diagnosis in the absence of TDC signal.

• Periodical: Applied Mechanics and Materials (Volumes 34-35)
• Pages: 296-300
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.34-35.296
• Online since: October 2010
• Authors: Zhao Qian Zhu, Wen Ming Zhang, Xiao Ming Zhang, Yu Peng Shi
• Keywords: Condition Monitoring, Cylinder Head Vibration Signal, Diesel Engine, Peak Identification

References

[1] Yao Jian-jun: Research on the Diesel Engine Cylinder Pressure. Wuhan University, (2006).

[2] Gao Hong-bin, Ouyang guang-yao. Misfire Detection of Diesel Engine Based on Analysis of Cylinder Head Vibration Signal [J]. Vehicle Engine, Vol. 2(2005) , pp.32-34.

[3] Lu Jin-ming. Research on Fault Diagnosis of Diesel Engine Using Vibration Signals of the Cylinder Head. Chinese Internal Combustion Engine Engineering, Vol. 29(2008) , pp.72-76.

[4] Huang Qiang, Liu Yong-chang, Liu Hui-meng, etc. Fault Diagnosis Study of the Inlet Exhaust Based on Vibration Signal. Vehicle Engine, Vol. 10(2002) , pp.34-37.
