The Electric Field Analysis of the Warm Dielectric HTS Power Cable

Abstract:

The 75 m/1.5 kA AC high-temperature superconducting cable(75 m HTS cable) and the 360 m/10 kA DC HTS power cable (10 kA HTS cable), which are supported by Chinese State 863 projects, are both of the demonstration projects facing to industrialization application. The characteristic in structure of warm dielectric (WD) insulated HTS cable is introduced. The electric field distribution characteristic at the cryogenic envelope body, the end-point of metallic shield layer at the end of the HTS cable and the connection sections are analyzed; the controlling method for electric field stress is introduced; there is serious concentration of electric field both in the termination and the connection sections between the termination and the cryogenic envelope. It is difficult to calculate the electric field of the part with irregular or special structure by resolution analytical methods, and the numerical analysis method is effective to analyze the electric field of the shaped structural part for HTS cable. The electric analysis, simulation, the design and processing of insulation for the two cables are finished based upon these two cables run well by now.

• Periodical: Applied Mechanics and Materials (Volumes 347-350)
• Pages: 1276-1282
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.347-350.1276
• Online since: August 2013
• Authors: Yu Ping Teng, Shao Tao Dai, Li Ye Xiao, Dong Zhang, Bing Song Cheng
• Keywords: Demonstration Project, Electric Field, HTS Cable, Insulation, Termination, Warm Dielectric
