A Pneumatic Miniature Robotic Control System Based on Improved Single Neural Network PID Control

Abstract:

At present pneumatic miniature robotic control system usually adopts PID control strategy. The basic PID control strategy has its limitations. To cope with this problem, a lot of methods to optimize this strategy have been researched. In the paper an improved single neural network PID control strategy is put forward. The control strategy is a single neuron adaptive controller with adjusting weighting coefficient. Both simulation and experimental results indicate that this scheme is a feasible control method for the 3-dof pneumatic miniature robotic control system.

• Periodical: Applied Mechanics and Materials (Volumes 347-350)
• Pages: 733-738
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.347-350.733
• Online since: August 2013
• Authors: Wen Li, Hong Min Li
• Keywords: Inchworm Movement, PID, Rubber Actuator, Single Neural Network

References

[1] Tondu B, Ippoloto S, Guiochet J. A seven DOF robot-arm driven by pneumatic artificial muscles for humanoid robots, The International Journal of Robotics Research, Vol. 24, 2005, pp.257-274.

DOI: 10.1177/0278364905052437

[2] Anthierens C, Libersa C, Touaibia M. Micro robots dedicated to small diameter canalization exploration, in Proc. IEEE International Conference on Intelligent Robots and Systems, Vol. 1, 2000, pp: 480-485.

DOI: 10.1109/iros.2000.894650

[3] Phee, L, Menciassi, A, Gorini, S, Wrnorio, G, Arena, A, Dario, P, An Innovative Locomotion Principle for Minirobots Moving in the Gastrointestinal Tract, Proc. of IEEE Int. Con$ on Robotics & Automation, pp.1125-1130.

DOI: 10.1109/robot.2002.1014694

[4] Louis Phee, Dino Accoto, Arianna Menciassi, Cesare Stefanini, Maria Chiara Carrozza, Paolo Dario: Analysis and Development of Locomotion Devices for the Gastrointestinal Tract, IEEE Transactions on Biomedical Engineering, Vol: 49 Issue: 6 , Jun. 2002, pp.613-616.

DOI: 10.1109/tbme.2002.1001976

[5] Suzumori K, Likura S, Tanaka H. Applying a flexible microactuator to robotic mechanisms, IEEE International Conference on Robotics and Automation, Sacramento, CA. pp: 21-27, April (1991).

DOI: 10.1109/robot.1991.131850

[6] H.W. LIU. Material Mechanics, Higher Education Publishing Company, Beijing, pp: 93-156, (2004).

[7] J.L. WU. Elastic Mechanics, Tongji University Publishing Company, Shanghai, pp: 140-167, (2010).

[8] Jimwan Lim, Hyunjun Park, Sunmoo Moon. Pneumatic Robot Based on Inchworm Motion for Small Diameter Pipe Inspection, in Proc. IEEE International Conference on Robotics and Biomimetics, pp: 330-335, (2007).

DOI: 10.1109/robio.2007.4522183

[9] J.K. LIU. Advanced PID control And MATLAB simulation, Electronics Industry Publishing Company, Beijing, pp: 153-159, (2004).
