Preliminary Research on Mechanical Behavior of Steel Frame Filled with Steel Plate Shear Wall after Exposure to Overall Stage of Fire

Abstract:

For a further study on the fire-resistant performance of steel plate shear wall under overall stage of fire, a numerical analysis model of steel frame filled with steel plate shear wall was built with the finite element software ANSYS. The stress and displacement distribution at different moments were calculated through the thermal structural coupling analysis acording to ISO-834 standard fire curve, by reasonable selection of the thermal parameters, which showed the highest temperature appeared on the heated side of the beam in the process of heating up, while the highest temperature in the stages of cooling and natural cooling appeared in the column-beam connection; The temperature of structure was elevated for 11minutes, then dropped for 64.5minutes and finally the structure was cooled in the air for 60.5minutes. The whole process shows that the lateral load-bearing capacity of the steel frame filled with steel plate shear wall was reduced by about 30 percent, compared to room temperature.

• Periodical: Applied Mechanics and Materials (Volumes 351-352)
• Pages: 90-94
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.351-352.90
• Online since: August 2013
• Authors: Xue Kun Liao, Fang Fang Wei, Li Hua Qu
• Keywords: Overall Stage of Fire, Steel Frame, Steel Plate Shear Wall, Thermal Structure Coupling Analysis

References

[1] Bai Ying. Research on Structural Performance and Fire-resistance of Large-space Steel Structures under Fire Conditions[D]. Bei Jing: Department of Civil Engineering, Tsinghua University，2008. (in Chinese).

[2] Wang Y C. Steel and Composite Structures: Behavior and design for fire safety. London: Spon Press, (2002).

[3] Newman G M, Robinson J T, Bailey C G. Fire Safe Design: A New Approach to Multi-Storey Steel-Framed Buildings. The Steel Construction Institute, (2000).

[4] Xiaodong Li, Yuli Ce, Litang Gao，Rongbao Jia, Mingrui Fang. Experimental study on fire-proof behavior of one-story, one-bay steel frame. journal of building structures，2006, 27(6). (in Chinese).

[5] Yang H, Han L H, Wang Y C. Effects of heating and loading histories on post-fire cooling behavior of concrete-filled steel tubular columns[J]. Journal of Constructional Steel Research, 2008, 64(5): 556-570.

DOI: 10.1016/j.jcsr.2007.09.007

[6] International Standard ISO834. Fire-resistance tests element of building construction [S]. Amendment1, amendment 2, (1980).
