Stability Analysis of a New Frame Formwork Support

Abstract:

Considering the structural characteristics of high-rise residential with regular plane design, simple load condition and small height change of standard floor, a new frame formwork support is proposed. According to eigenvalue buckling analysis, the research proves its stability bearing capacity and mechanics properties. MF1225 bearing capacity is determined by the out-of-plane stiffness. Ledger and bottom reinforcing tube improves the longitudinal stiffness and integrity in frame system.

• Periodical: Applied Mechanics and Materials (Volumes 351-352)
• Pages: 945-949
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.351-352.945
• Online since: August 2013
• Authors: Li Wu Nie, Zhen Hua Liu, Gu Yue Han, Ji Gang Zhang
• Keywords: ANSYS, Finite Element Analysis (FEA), Frame Formwork Support, Stability Bearing Capacity

References

[1] Lin-hua Xiao: Sichuan Building Materials, Vol. 4(2008), pp.474-476. In Chinese.

[2] JGJ128—2010, Technical code for safety of frame scaffolding with steel tubules in construction. In Chinese.

[3] Xin-min Wang: ANSYS numerical analysis of engineering structures (China communication Press, Beijing 2007). In Chinese.

[4] Xin-min Wang, LI Yi-Qiang: ANSYS analysis unit and application(China communication Press, Beijing 2011). In Chinese.

[5] Xi-yue Liu: Stability bearing capacity study of frame scaffolding with steel tubes. Central South University, Changsha 2010. In Chinese.
