Seismic Active Nonlinear Control of an Isolated Highway Bridge

Abstract:

Active control and passive base isolation strategies are exerted on one continuous isolated prestressed concrete bridge. The goal of this study is to check the applicability of the LQR control law on the isolated continuous or rigid-connection type bridge, to find a more effective control strategy when nonlinearity is introduced. A spaced frame finite-element model is developed by a MATLAB program coded by the author, its validity is checked through comparisons with a sap2000 model. In this program, the nonlinearities of 3 different columns and 5 isolators are considered with their bilinear force-deformation relationship. the factors such as the control devices, sensors, and the corresponding noises and time delay are all considered in the model. Model reduction technique was applied to set up the controllers. The seismic response measurements and regulated outputs are adjusted to optimize control effects.

• Periodical: Applied Mechanics and Materials (Volumes 353-356)
• Pages: 1800-1805
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.353-356.1800
• Online since: August 2013
• Authors: Jing Ning*
• Keywords: Base Isolation, Continuous Bridge, Finite Element Method (FEM), LQG Control, Nonlinearity, Spaced Frame

References

[1] Ping Tan and Anil K Agrawal (2006), Benchmark Control Problem for Seismic Response Analysis of a Highway Bridge, Proc. 4th International Conference on Earthquake Engineering , October 12-13, Taipei, Taiwan.

[2] Gursoy Turan, Active Control of a Cable-Stayed Bridge Against Earthquake Excitations, PhD thesis, Department of Civil Engineering, University of Illinois at Urbana-Champaign, (2001).

[3] Priestley M.J.N., Seible F., Calvi G.M., Seismic Design and Retrofit of Bridges, John Wiley and Sons, Inc., (1996).

DOI: 10.1002/9780470172858

[4] Wane-Jang Lin(1998), Dynamic Analysis of Base-Isolated Highway Bridge, Available online at http: /www. isr. umd. edu/~austin/aladdin. d/wjlin-bridge. html.

[5] Dyke, S. J., Caicedo, J. M., Turan, G., Bergman., L. A. and Hague S. 2003. Phase I Benchmark Control System for Seismic Response of Cable-Stayed Bridges, J. Strut. Engn., 129(7).

DOI: 10.1061/(asce)0733-9445(2003)129:7(857)

[6] Kim, S. B. and Spencer, B.F. Jr. (2004), Eigenmode Reduction Method and its Application to Smart Base Isolated Building, US-Korea Workshop on Smart Structures Technologies, Seoul, Korea, September 2-3, (2004).

[7] A.J.M. Ferreira, MATLAB Codes for Finite Element Analysis, Springer, (2009).
