Numerical Simulation Analysis of Hole Shape Design of Self-Thermal Insulation Perforated Brick

Abstract:

The hole shape design of perforated brick directly affects thermal insulation performance of wall. In order to study the influence of shape, size and configuration of perforated brick on the insulation performance, six kinds of perforated brick with different hole shape were designed, and their temperature field were simulated with finite element method. The results show that the insulation performance of perforated brick with square hole is the best. Filling brick holes with thermal insulation materials can improve the insulation performance of perforated brick, Besides; The thermal conductivity of perforated brick affects its thermal resistance, so brick materials with low thermal conductivity should be developed for the achievement of energy-saving standard of wall thermal resistance.

• Periodical: Applied Mechanics and Materials (Volumes 357-360)
• Pages: 1089-1092
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.357-360.1089
• Online since: August 2013
• Authors: Xiao Ping Feng, Yong Fu Yu, Bo Jiang, Wei Bai
• Keywords: ANSYS, Hole Shape Design, Nonlinear Finite Element, Perforated Brick, Thermal Resistance

References

[1] Yanhua Ye, Weimin Sun, etc. Theory analysis of thermal insulation coefficient of concrete hollow block wall [J]. Insulation Materials and Building Energy Saving, 2002, 5: 27-29. (In Chinese).

[2] Baoguo Ma, Xiang Huang, etc. Research on thermal simulation of fired perforated brick by ANSYS [J]. Brick & Tile, 2009, 12: 14-16. (In Chinese).

[3] Hanxiang Peng, Jianwei Yuan, Sheng Xu. Study on the numerical simulation of the temperature field of the energy saving perforated concrete brick wall [J]. Shanxi Architecture, 2008, 34: 23-24. (In Chinese).
