Ultrasonic Testing of Lightweight Fine Aggregate Concrete in Time and Frequency Domains

Abstract:

Non-destructive techniques (NDT) have been used to assess the condition of existing concrete structures, to predict future performance, and to monitor the conditions of repaired systems and so on. One of the widely known NDT is the ultrasonic pulse velocity (USPV) method, which determines the travel time of the ultrasonic pulse through the tested material. Most studies were focused on the results expressed in time domain. However, the signal of ultrasonic pulse in time domain can be transformed into frequency domain, through Fast Fourier Transform (FFT). This paper shows a comparison of changes in the pulse velocity and frequency domain signals of concrete for various load histories using lightweight fine aggregates. The results demonstrate that the signals in frequency domain of ultrasonic pulse of lightweight fine aggregate concrete does not show any significant difference comparing with those of normal concrete. The reduction trend of peak frequency was found to be more influenced by the stress levels rather than the ultrasonic pulse velocity.

• Periodical: Applied Mechanics and Materials (Volumes 357-360)
• Pages: 655-658
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.357-360.655
• Online since: August 2013
• Authors: Jee Sang Kim, Kyung Suk Yoo
• Keywords: Concrete, Frequency Domain, Lightweight Fine Aggregates, Nondestructive Testing (NDT), Replacement Rate, Ultrasonic Pulse Velocity

References

[1] Malhotra, V.M. and Carino, N.J., Handbook on Nondestructive Testing of concrete, CRC Press, U.S.A. (1991).

[2] Prassianakis, I.N. and Prassianakis, N.I., Ultrasonic testing of non-metallic materials: concrete and marble, Theoretical and Applied Fracture Mechanics, vol. 42, pp.191-198. (2004).

DOI: 10.1016/j.tafmec.2004.08.007

[3] Maierhofer, C., Reinhardt, H.W. and Dobmann, G., Non-destructive evaluation of reinforced concrete structures Vol. 2: Non-destructive testing methods, Woodhead Publishing, U.K. (2010).

DOI: 10.1533/9781845699604

[4] Wu, T.T. and Lin, T.F., The stress effect on the ultrasonic velocity variations of concrete under repeated loading, ACI Materials Journal, Vol. 95, No. 5, pp.519-524, (1998).

DOI: 10.14359/394

[5] Qasrawi, H. Y and Marie, I.A., The use of USPV to anticipate failure in concrete under compression, Cement and Concrete Research, Vol. 33, pp.2017-2021. (2003).

DOI: 10.1016/s0008-8846(03)00218-7

[6] Treiber, M., Kim, J., Qu, J. and Jacobs, L.J. Effects of sand aggregate on ultrasonic attenuation in cement-based materials, Materials and Structures, Vol. 43, Supplement. 1, pp.1-11. (2010).

DOI: 10.1617/s11527-010-9587-7

[7] Kim, J.S., Kim, I.B., and Yoo, K.S. An experimental comparison of ultrasonic pulse velocity and frequency domain signal of concrete, Proceedings of 5th Int. Conference on ACF, Pattaya, Thailand, p.96. (2012).

[8] RILEM Recommendation NDT 1, Testing of Concrete by the Ultrasonic Pulse Method, Paris. (1972).
