Strain Analyzing of Concrete Creep of Xiaolangdi Sediment Tunnel Lining over Tensioning and Operation Periods

Abstract:

Xiaolangdi sediment tunnel is the first waterway engineering used un-bonded circumferential pre-stressed lining in China. Based on data obtained by concrete strain meters over tensioning and operation periods, strain of concrete creep of sediment tunnel lining was analyzed. The results show that concrete creep developed over tensioning period is 26.4% of total strain and 35.8% of elastic strain respectively; Creep strain had a good linear relation with pre-stress and loading time and can be calculated by εc=ασiti , which are agree with the measured results; Over operation period, concrete creep strain can be analyzed by rejecting the effect of temperature and water level from the total strain.

You might also be interested in these eBooks

Architecture, Building Materials and Engineering Management

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 357-360)

Pages:

928-931

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.357-360.928

Citation:

Cite this paper

Online since:

August 2013

Authors:

Chu Ne Sui, Jing Fu Kang, Xiao Zhe Wang, Xiao Ping Xu

Keywords:

Concrete Creep, Elastic Strain, Resting Period, Tensioning Period

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] WANG Jinfeng, WU Guangyu. Simulation Theory and Engineering Application of Bridge Structure. Hanzhou: Zhejiang University Press (2007).

Google Scholar

[2] YUAN Ming, YAN Donghuang. Concrete Creep Effect of PC Continuous Box Girder Bridge Based on PC Composite Unit. Journal of Highway and Transportation Research and Development. Vol. 29(2012), pp.38-45.

Google Scholar

[3] Bazant, Z.P. Prediction of concrete creep and shrinkage: past, present and future. Nuclear Engineering and Design. Vol. 203(2001), pp.27-38.

DOI: 10.1016/s0029-5493(00)00299-5

Google Scholar

[4] ZHANG Han-yi, ZHOU Ling-yu, HE Gui-chao, XIAO Jin-min. Effect of creep on the construction of linear control of large-span prestressed concrete continuous box beam bridge. JOURNAL OF RAILWAY SCIENCE AND ENGINEERING. Vol. 9(2012), pp.13-18.

Google Scholar

[5] Kang Jingfu, Yin Baohe, Lin Xiushan. Concrete prestress analysis of Xiaolangdi desilting tunnel Lining. Yellow River. Vol. 24(2002), pp.28-29.

Google Scholar

[6] Zhang Shiduo. Modern concrete foundation theory. Shanghai: Tongji University Press (1994).

Google Scholar

[7] Li Guoping. Prestressed concrete structural design principle Beijing: People's Communications Press (2000).

Google Scholar
