Research on Loading Test Scheme of Vehicular Bridge-Footbridge Combined Double-Deck Cable-Stayed Bridges

Abstract:

In order to check whether the bridge structure is in good working condition, meeting the requirements of carrying capacity and traffic capacity, loading test should be conducted to the Huiketing No.1 Bridge in Mianyang city. The bridge is a double-deck cable-stayed bridge, the upper deck of which works as a footbridge and is connected by 6 chain poles to the lower deck which works as a vehicular bridge. Since the bridge structure is novel, the working stress state is complicated and the coupling effect of the two decks is notable, little referential experience could be found from other bridges. The loading test uses sandbags as equivalent to pedestrian loads on the footbridge and adopts heavy trucks to imitate the design vehicle loads on the vehicular bridge. According to the structural symmetry of the whole bridge and the analysis of its static and dynamic performances in the finite element software, the optimized loading project is finalized. Test methods and analysis results of this footbridge can be used as reference in loading test of similar bridges in the future.

• Periodical: Applied Mechanics and Materials (Volumes 361-363)
• Pages: 1081-1085
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.361-363.1081
• Online since: August 2013
• Authors: Meng Yan, Yong Qing Yang, Yuan Yuan, Xiang Lin Zeng
• Keywords: Coupling Effect, Double-Deck Cable-Stayed Bridge, Dynamic Load Test, Footbridge, Loading Scheme, Static Load Test, Vehicular Bridge

References

[1] Yan Meng. Seismic response analysis of long-span tied-arch bridges[J]. Master degree thesis. Chengdu: Southwest Jiaotong University, (2011).

[2] YC4-4/1982 Technical specification for long-span concrete bridge test[S].

[3] JTG/T J21-2011 Technical specification for bearing capacity evaluation of highway bridge[S]. Beijing: China Communication Press, (2011).

[4] Xia Jiazhong. Static and dynamic loading test of WuhanYangtze River Bridge[J]. China Railway Sciences, 2001, 22(5): 81-84.

[5] Chen Jianghua. Study on Loading Test Scheme of Caiyuanba Yangtze River Bridge, Master degree thesis[J]. Chongqing: Chongqing Jiaotong University, (2011).
