The Nonlinear Finite Element Analysis of Prestressed Concrete Box Girder

Abstract:

Using Midas/Civil, a nonlinear finite element software, to establish solid element, analyse the process of the construction of a prestressed concrete simply supported box girder which length 32m, this box girder is located on the Shijiazhuang-Wuhan Passenger Dedicated Line, gained the maximum stress and displacement at the control section. Comparative analysis of the simulation results with the monitoring data which gained at the construction site, The results of both are substantially the same, achieve the purpose of assessing the safety of the construction process and the reasonableness of the structure model about the box girder.

• Periodical: Applied Mechanics and Materials (Volumes 361-363)
• Pages: 1384-1388
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.361-363.1384
• Online since: August 2013
• Authors: Meng Chan Zhou, Qun Yang Liu, Jun Su
• Keywords: Box Girder, Midas/Civil, Nonlinear Finite Element, Pre-Stress

References

[1] Miao Tian. Finite Element Model of Prestressed Concrete Structure [D]. Chongqing: Chongqing Jiaotong University(2009).

[2] Dianguo Sun. Study on Mechanics Effect of Simple support Box Girder Used in High-speed Passenger Railway [D]. Chengdu: Southwest Jiaotong University.

[3] Gao Ang, Yu Zehong, Lv Yunfeng. Simulation and Analysis on Dynamic Load of Harbin-Dalian Passenger Dedicated Line Prestressed Box Girder [J]. Journal of Changsha University of Science and Technology (Natural Science), 2010, 7(1): 39-51.

[4] Junli Liu, Tianqing Yu, Tianliang Wang. The Test and FEM Analysis for a Prestressed Box-girder of Light Railway in Wuhan [J]. Journal of Hubei University of technology. 2003, 18(3): 8-15.
