Numerical Simulation and Experimental Study on Fluid-Filled Hemispherical Shell under Impact

Abstract:

The dynamic response of fluid-filled hemispherical shell in mass impact is studied by experiment using DHR9401. Combining the time history of impact force with experimental observation of the deformation process, it can be seen that the dynamic response can be divided into four stages: the flattening around the impact point, the forming and expanding outward of shell plastic hinge, the plastic edge region flatten by the punch, and elastic recovery. The experimental results show that: Because the shell filled with liquid, the local impact load that the shell suffered is translated into area load and loads on the inner shell uniformly, so that it has a high carrying capacity. Numerical simulation is used to study the time history of energy absorption of different shell structures. The result shows that the crashworthiness of sandwich fluid-filled shell is improved greatly. Under the certain impact energy, deformation of its inner shell is very small, which can provide effective security space.

• Periodical: Applied Mechanics and Materials (Volume 364)
• Pages: 172-176
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.364.172
• Online since: August 2013
• Authors: Hui Wei Yang, Bin Qin, Zhi Jun Han, Guo Yun Lu
• Keywords: Dynamic Response, Fluid-Filled Shell, Hemispherical Shell, Impact

References

[1] D.P. Updike: On the large deformation of a rigid plastic spherical shell compressed by a rigid plate: Journal of Engineering for Industry. Vol. 94(1972), p.949–955.

DOI: 10.1115/1.3428276

[2] H.M. Wen, N. Jones: Experimental investigation into the dynamic plastic response and perforation of a clamped circular plate struck transversely by a mass: Proc. Inst. Mech. Eng., J. Mech. Eng. Sci. Vol. 208(1994), p.113–134.

DOI: 10.1243/pime_proc_1994_208_107_02

[3] R. Kitching, R. Houston and W. Johnson: A theoretical and experimental study of hemi spherical shells subjected to axial loads between flat plates: International Journal of Mechanical Sciences, Vol. 17(1975), p.693–703.

DOI: 10.1016/0020-7403(75)90072-7

[4] N.K. Gupta, G.L. Eswara Prasad and S.K. Gupta: Axial compression of metallic spherical shells between rigid plates: Thin Walled Struct. Vol. 34(1999), p.21–41.

DOI: 10.1016/s0263-8231(98)00049-4

[5] N.K. Gupta, N. Mohamed Sheriff and R. Velmurugan: Experimental and theoretical studies on buckling of thin spherical shells under axial loads: Int J Mechanical Sciences, Vol. 34(2008), p.422–432.

DOI: 10.1016/j.ijmecsci.2007.10.002

[6] N.K. Gupta, N. Mohamed Sheriff and R. Velmurugan: Experimental and numerical investigations into collapse behaviour of thin spherical shells under drop hammer impact: Int J Solids Struct. Vol. 44(2007), pp.3136-3155.

DOI: 10.1016/j.ijsolstr.2006.09.014

[7] N.K. Gupta, Venkatesh: Experimental and numerical studies of dynamic axial compression of thin wall spherical shells: Int J of Impact Engineering. Vol. 30(2004), pp.1225-1240.

DOI: 10.1016/j.ijimpeng.2004.03.009

[8] A.N. Kinkead, A. Jennings, J. Newell and J.C. Leinster: Spherical shells in inelastic collision with a rigid wall tentative analysis and recent quasi static testing: Journal of Strain Analysis. Vol. 29(1994), p.17–41.

DOI: 10.1243/03093247v291017

[9] J.G. Ning, G.T. Yang: Failure Analysis of Elastic-Plastic Thin Spherical Shells Impacted by a Flat-Nose Rigid Missile: Jounal of Beijing Institute of Technology. Vol. 17(1997), pp.545-551.

[10] J.G. Ning: Dynamic analysis of elastic plastic thin shperical shells under impact: ACTA Mechanica Solida Sinica. Vol. 19(1998), pp.313-320.

[11] J.C. Mu, L.M. Zhao, W.Z. Wu: An Experimental Research on the Dynamic Response and Buckling of a Shallow Spherical Shell: Journal of Taiyuan University of Technology. Vol. 22(1991), pp.1-6.
