Design and Optimization of the X Direction Sideway Face Camber Curve of Super-Span Cross-Rail

Abstract:

As super-span cross-rail of NC heavy-duty planer type milling machine tool has a super span and heavy mass,it will deform seriously after installed. Machining an arch camber on X direction sideway in advance is used to compensate for influence caused by its deformation.Finite-element method is used to analysis deformation of super-span cross-rail when working.Multinomial is used to fit deformation curve based on deformation of the X direction sideway of cross-rail when bottom-slide and ram at each position.At the same time this paper takes into consideration of the impact on camber curve as the bottom-slides span brings about 2 deformation curves.A method based on 2 deformation curves is put forward to design and optimize the camber curve. By comparing various camber curves effect on the deformation of milling head,this article proves that the optimization method can effectively reduce the influence of cross-rails deformation on machine tools accuracy.

• Periodical: Applied Mechanics and Materials (Volume 364)
• Pages: 3-9
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.364.3
• Online since: August 2013
• Authors: Li Gang Cai, Zhi Liang Wang, Tie Neng Guo
• Keywords: Camber Curve, Deformation Curve, Optimization, Super-Span Cross-Rail

References

[1] ZHANG Bopeng, ZHANG Niansong. Self-evolutionary compensation of machine tool crossbeam deformation induced by gravity[J]. Journal of Tsinghua University(Science and Technology), 2006，46(2)：191-193.

[2] Luo Chuan-lin, Li Duan-neng. Design and Research of the Structural of Cross-rail in the Planer Type Machines. [J] Mechanical & Electrical Engineering Technology. 2006，35(3)：45-47. (in Chinese).

[3] XIE Li-ming, LI Da-ming, SHEN Hao, et al. Optimum Design of scene Milling Machine Beam Based on Finite Element Analysis. Modular Machine Tool & Automatic Manufacturing Technique, 2008, 9：73~75. (in Chinese).

[4] M. Zatarain, E. lejardi, F. Egana. Modular Synthesis of Machine Too1s [J]. Annals of theCIRP, 1998, 47(1)：333~336.

DOI: 10.1016/s0007-8506(07)62845-5

[5] GUO Tie-neng, XI Fang-jian, CAI Li-gang, et al. Load Curve Analysis and Experimental Study of Long span and Heavy load Crossbeam[J]. Journal of Beijing University of Technology, 2011, 37(8)：1129~1135. (in Chinese).

[6] GUO Tie-neng, CUI Ya-hui, CAI Li-gang, et al. The influence of the chucking mode on the manufacture of the Z-guide face camber curve of Super-span beam [J]. Journal of Beijing University of Technology, To be published. (in Chinese).

[7] CHENG Qiang, DONG Xue-jiao, LIU Zhi-feng et al. Deformation Analysis of Slideway Contact of a Long Span and Heavy Load Crossbeam [J]. Journal of Beijing University of Technology. 2012，38(1)：12~16. (in Chinese).

[8] JEFFREY C. LAGARIAS, JAMES A. REEDS, MARGARET H. WRIGHT, AND PAUL E. WRIGHT. CONVERGENCE PROPERTIES OF THE NELDER-MEAD SIMPLEX METHOD IN LOW DIMENSIONS [J] SIAM Journal on Optimization, 1998, 9(1): 112~147.

DOI: 10.1137/s1052623496303470
