Mathematical Model Establishment of Prefabricated Hole Flange-Forming of Unequal Diameter Tee Pipe

Abstract:

Based on the principle that in the deformation zone the length of bore plain wire does not change, a mathematical model of the prefabricated hole flange-forming of unequal diameter tee pipe is established, for the difficult problem of the flange-forming prefabricated hole size design for tee pipe. To solve the mathematical model, a numerical method and a software system for The solution of the mathematical model is established. In order to verify the reliability of this article to build the mathematical model and its solution, taking engineering for example, apply the method of finite element simulation to verify the mathematical model and the solving system, and the results show that the mathematical model constructed in this paper can relatively accurately make calculation of prefabricated hole size of flange-forming of unequal diameter tee pipe.

• Periodical: Applied Mechanics and Materials (Volume 364)
• Pages: 500-503
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.364.500
• Online since: August 2013
• Authors: Zhong Lei Wang, Zhao Dong Li, Xin Kai Zhang
• Keywords: Finite Element Method (FEM), Flange Forming, Prefabricated Hole, Unequal Diameter Tee Pipe

References

[1] M.J. Ni : Welding Machines. Vol. 31(10)(2001), p.37.

[2] H. Hui: Chemical Equipment and Piping Vol(6)(2004) , p.60.

[3] S. Y Luo.T. Petrochemical Equipment, Vol22(1)(1993), p.43.

[4] W.J. Ye. Natural Gas and Oil , Vol. 13 (3)(1995), p.40.

[5] F.L. Gao: Thermal Processing, Vol. (6)(2003) , p.19.

[6] Z.D. Li, J.Z. Yu, Z.L. Wang, et al: Thermal Processing, Vol. 13(23)2011: 75.
