Pseudo-Dynamic Analysis and Construction Methods of Substructure for Division Plate of New Tank

Abstract:

Combined with practical experience a kind of new horizontal storage tank with separate plate was put forward. In view of the lack of experience in the design of the new tank and limitations of carrying out shaking table test for full scale horizontal storage tank, the pseudo-dynamic analysis of separate plate substructure with 5m diameter is done by using ANSYS finite element software combined with the actual engineering. The fluid loads action and mechanical model were simplified, and elastic-plastic mechanical properties of separate plate substructure under the cyclic loading actions were investigated, then deformation and stress distribution of separate plate were obtained. The design thickness for separate plate which in the horizontal storage tank is verified by finite element analysis and the horizontal tank construction methods is given. These can provide technical support to improve the practical design of large horizontal storage tank.

• Periodical: Applied Mechanics and Materials (Volumes 368-370)
• Pages: 1547-1550
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.368-370.1547
• Online since: August 2013
• Authors: Wei Wu, Jing Ji
• Keywords: Construction Method, Horizontal Storage Tank, Pseudo-Dynamic Analysis, Substructure

References

[1] GB50009-2012: Code for load design of building structures (China Building Industry Press, China 2012) (In Chinese).

[2] Wenhua Hao: ANSYS Civil Engineering Application Examples (China Water Power Press, China 2005) (In Chinese).

[3] Guangyuan Wang. Structural dynamics (China Building Industry Press, 2006) (In Chinese).

[4] GB50023-2012: Code for Design of Steel Structures (China Building Industry Press, China 2012) (In Chinese).
