Analytical Robust Design of a Gear Milling Machine Headstock

Abstract:

Headstock is a key component of gear milling machine. The dynamic functional performance of the headstock is usually influenced by uncertainties of both geometric and non-geometric design parameters. A new mathematical model to represent relationships among first frequency and design parameters of the headstock were derived with Rayleigh method. Then, a larger-the-better and smaller-the-better robust analysis and optimization model was developed. The sensitivity analysis results show that height of the headstock makes a great impact on the first frequency. Through robust optimizations, the first frequency is scaled up by 3.35 percent while minimizing the variance of the first frequency.

• Periodical: Applied Mechanics and Materials (Volumes 37-38)
• Pages: 162-165
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.37-38.162
• Online since: November 2010
• Authors: Yong Liang Chen, Shuang Liu, Han Tao Wang, Pei Hua Gu
• Keywords: Gear Milling Machine, Headstock, Robust Design, Robustness, Variance

References

[1] L.Z. Chen: Robust Design (China Machine Press, China 2000) (in Chinese).

[2] H.G. Beyer and B. Sendhoff: Computer Methods in Applied Mechanics and Engineering, Vol. 196 (2007), No. 33, pp.3190-3218.

DOI: 10.1016/j.cma.2007.03.003

[3] P.H. Gu, H.S. Lu and B. Spiewak: Annals of the CIRP, Vol. 53 (2004), No. 1, pp.129-133.

[4] B.Q. Huang and X.P. Du: Structural and Multidisciplinary Optimization, Vol. 34 (2007), No. 2, pp.123-137.

[5] J. Zhang; N.S. Bao; G.Z. Zhang and P.H. Gu: Frontiers of Mechanical Engineering in China, Vol. 4 (2009), No. 2, pp.203-214.
