Dynamic Analysis of a Calibration Mechanism

Abstract:

In order to verify the reliability of a calibration mechanism including a motion component used in the satellite, the dynamic analysis for this mechanism is conducted with modal coordinate reduction method. Firstly, FEM software ABAQUS is employed to calculate the eigenfrequency and mode shapes of this mechanism. Then, the transfer function at some key points can be acquired by coordinate transformation from its original format in modal coordinate. Finally, the power spectral density at the key points are obtained and compared with the results of random vibration experiments to prove the dynamics analytical validity.

• Periodical: Applied Mechanics and Materials (Volumes 37-38)
• Pages: 366-369
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.37-38.366
• Online since: November 2010
• Authors: De Wei Sun, Zhi Gang Chen, Guang Yu Zhang
• Keywords: Calibration Mechanism, Dynamic Analysis, Modal Reduction, Random Vibration Experiment

References

[1] C. Thompson: Classical Equilibrium Statistical Mechanics (Oxford University Press, New York, 1988).

[2] ABAQUS v6. 7 help document on http: /www. simulia. com/support/documentation. html.

[3] S. Tuerkay and H. Akcay: Journal of Sound and Vibration, Vol. 282 (2005), pp.114-118.

[4] G. C. Marano, S. Sgobba, R. Greco and M. Mezzina: Journal of Sound and Vibration, Vol. 313 (2008), pp.476-480.

[5] D. Sun, G. Zhang, Q. Zhang and G. Wu: Optics and Precision Engineering, Vol. 17 (2009) No. 2, pp.369-372.

[6] D. Chen, R. Zhou and Y. Li: Acta Photonica Sinic, Vol. 33 (2004) No. 10, pp.1248-1250.
