Experimental Investigation and Research on Forming Process of Micro Flat-Wire

Abstract:

The aim of this study is to get a better understanding of Micro Flat-Wire Roll Forming Technology. There are three methods for Mirco flat-wire forming, i.e., drawing, extrusion, and rolling. Without replacing the equipment, rolling method only demands to adjust the relative roll gap between the pressure and the wire deformation that it can produce different specifications of mirco flat-wire. The rolling equipment was introduced and can be divided into three parts, the mechanism section, the control part and the wire-locating device. Furthermore, the rolling process parameters were summarized as well. The effect of rolling amount and rolling speed on the wire surface quality was also discussed.

• Periodical: Applied Mechanics and Materials (Volumes 37-38)
• Pages: 417-423
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.37-38.417
• Online since: November 2010
• Authors: Chun Chiu Fok, Zhong Ning Guo, Zhao Qin Yu, Jian Wen He
• Keywords: Rolling , Forming Process, Micro Flat-Wire

References

[1] Information on http: /www. china-tbh. com/02/yx/yixing. htm.

[2] Y.S. Zhang: Non-Ferrous Metallurgical Equipment, Vol. 1 (2002) No. 1, pp.5-6. (in Chinese).

[3] Ю.C. Эьков: Wires and Cables, Vol. 1 (1991) No. 6, pp.61-62.

[4] S.L. He, C.G. Zhang, X.W. Wang, and B. Xie: Tool Engineering, Vol. 3 (2005) No. 3, pp.27-30. (in Chinese).

[5] B.Y. Song, Z.X. Kuai and Y.W. Liu: Wires and Cables, Vol. 1 (2001) No. 1, pp.17-18. (in Chinese).

[6] B.Y. Song, X. Yu and J.G. Chen: Transformer, Vol. 39 (2002) No. 9, pp.32-33. (in Chinese).

[7] Z.R. Qiu: Base of Precision Machine Design (China Machine Press, China 2007).
