Parameters Design and Motion Analysis of Rolling-Cut Shears

Abstract:

Based on analysis and transformation of structure and parameters of the introduced 4300mm rolling-cut shears, the paper designed a new rolling-cut shears of large span. The paper gives a comparative study of the up blade locus and parameters between introduced 4300mm rolling-cut shears and new large span rolling-cut shears, to arrive at a conclusion that the new large span rolling-cut shears provide longer cutting steps.

• Periodical: Applied Mechanics and Materials (Volumes 37-38)
• Pages: 849-852
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.37-38.849
• Online since: November 2010
• Authors: Deng Yue Sun, Yang Zhao, Jian Dong Peng, Chong Shan Xu, Chun Guang Dong, Jun Wang, Ru Min Mei
• Keywords: Locus of Upper Blade, Offset, Rolling-Cut Shear

References

[1] X.S. Wang and J. Xing: Heavy Industrial & Hoisting Machinery, Vol. 15 (2007) No. 4, pp.28-30. (in Chinese).

[2] H.W. Wang: Rolling Machine Design (Machinery Industry Publications, China 1983).

[3] F.P. Cui, E. Sun and Y.C. Liu: Production and Quality Control of Plate (Metallurgy Industry Press Publications, China 2008).

[4] X.L. Meng and T.C. Wang: Equipment Manufacturing Technology, (2009) No. 6, pp.28-30. (in Chinese).

[5] D.Y. Sun, Y. Zhao and C.G. Dong: Heavy Machinery, (2010) No. 291, pp.39-41. (in Chinese).
