A Mathematical Principle and Application on Design of Planar Six-Bar Mechanism with unto Three-Ordered Intermission at Limit Position(s)

Abstract:

A non-iterative design method about high order intermittent mechanisms is presented. The mathematical principle is that a compound function produced by two basic functions, and then one to three order derivatives of the compound function are all zeroes when one order derivative of each basic function is zero at the same moment. The design method is that a combined mechanism is constructed by six bars; the displacement functions of the front four-bar and back four-bar mechanisms are separately built, let one order derivatives of two displacement functions separately be zero at the same moment, and then get geometrical relationships and solution on the intermittent mechanism. A design example shows that this method is simpler and transmission characteristics are better than optimization method.

• Periodical: Applied Mechanics and Materials (Volumes 37-38)
• Pages: 9-13
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.37-38.9
• Online since: November 2010
• Authors: Hong Xin Wang, Ning Dai
• Keywords: Combined Mechanism, Function Derivative, Mechanism Theory, Non-Iterative Design, Three-Ordered Intermission

References

[1] J. Chai: Study on Approximate Function Synthesis Theory and Method of Planar Six-bar Intermittent Mechanism (Ph.D., Dalian University of Technology, China 2003), pp.40-50.

[2] J.L. Li: Study on Approximate Function Synthesis Theory and Method of Planar Six-bar bi-Intermittent Mechanism (Ph.D., Dalian University of Technology, China 2005), pp.32-41.

[3] H.Y. Yu, Z.X. Wang and J.S. Li: Journal of Machine Design, Vol. 19 (2002) No. 6, pp.28-32 (In Chinese).

[4] H.Y. Lv: Journal of Suzhou Institute of Silk Textile Technology, Vol. 21 (2001) No. 4, pp.29-35 (In Chinese).

[5] A.M. Li and H.X. Wang: Journal of Machine Design, Vol. 26 (2009) No. 1, pp.43-45(In Chinese).

[6] H.X. Wang: Mechanical Transmission, Vol. 30 (2006) No. 1, pp.6-10(In Chinese).

[7] H.X. Wang, X. Duan and A.J. Li: Machine Design and Research, Vol. 21 (2005) No. 4, pp.16-18, 26 (In Chinese).

[8] H.X. Wang and A.J. Li: Journal of Machine Design, Vol. 21 (2004) No. 7, pp.34-35 (In Chinese).

[9] H.X. Wang and X. Duan: 12TH International Conference on Geometry and Graphics (Salvador, Brazil, August 6-10, 2006), Vol. E, pp.37-42.

[10] H.X. Wang: Journal of Machine Design, Vol. 23 (2006) No. 1, pp.47-49 (In Chinese).
