Virtual Simulation of Plastic Injection Technology for Medical Devices

Abstract:

This paper aims to present the simulation of technological process of components made by plastic injection using a computer within a orthotic device for human knee. Also, the aim of the work is to improve the final product quality and operating properties in different types of design and minimize material requirements for different anthropometric data quality in optimal conditions. The orthotic device addresses to people with walking disabilities, and aims to rehabilitate and ameliorate the pain caused by osteoarthritis disease. For the geometric modeling of components in order to obtain virtual mathematical model study we used ProEngineer application, which allows a detailed design and a high accurate technical approach. The model was imported into the Moldex3D application, being integrated within a XYZ coordinate system.To simulate the injection process we used only the component from the upper part of orthotic device. This paper presents advanced modeling elements, geometric mesh model into an advanced form of nodes and elements, plastic injection process analysis settings. It highlights the tensions, deformations and displacements in these parts during the injection process.

• Periodical: Applied Mechanics and Materials (Volume 371)
• Pages: 529-533
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.371.529
• Online since: August 2013
• Authors: Marius Catana, Daniela Tarniţă, Viorel Diorduc
• Keywords: Optimal Design, Orthotic Device, Plastic Injection, Virtual Simulation

References

[1] T.H.M. Nguyen, Accuracy of CAE Tools in Plastic Injection Molding, The 11th Asia Pacific Industrial Engineering and Management Systems Conference. (2010).

[2] A.Y. Peng, W.H. Yang, D.C. Hsu, Numerical Prediction of the Weld-line-Induced Strength Reduction for Injection-Molded Part, CoreTech System Co. Ltd., HsinChu 300, Taiwan, ROC. (2006).

[3] H.Y. Lin, C.H. Chang, W.B. Young, Experimental and analytical study on filling of nano structures in micro injection molding, International Communications in Heat and Mass Transfer. 37 (2010) 1477–1486.

DOI: 10.1016/j.icheatmasstransfer.2010.08.017

[4] S. Chianrabutra, A. Wongsto, T. Sirithanapipat, Balancing gate and runner systems for a family mold using CAE tools, Department of Mechanical Engineering, Kasetsart University, Thailand. (2004).

[5] C.C.A. Chen, J.C. Tang, L.M. Teng, Effects of mold design of aspheric projector lens for head up display, SPIE Proceedings. 7788 (2010).

DOI: 10.1117/12.861146

[6] S.H. Park, W.I. Lee, S.N. M, Y.E. Yoo, Y.H. Cho, Injection molding micro patterns with high aspect ratio using a polymeric flexible stamper, eXPRESS Polymer Letters. 5 (2011) 950–958.

DOI: 10.3144/expresspolymlett.2011.93

[7] S.C. Chen, P.S. Minh, I.S. Hsieh, Y.C. Chiou, Improve cooling effect of injection molding by pulsed-cooling method, Department of Mechanical Engineering, Chung Yuan Christian University, Taiwan, R.O.C. (2009).

[8] H.S. Park, X.P. Dang, Design and simulation-based optimization of cooling channels for plastic injection mold, New Technologies – Trends, Innovations and Research. (2012) 20-44.

DOI: 10.5772/32730

[9] T.B. Son, C.H. Tu, C.Y. Liu, Optimization of process parameters for car side mirror using Taguchi Method and artificial neural network, Department of Mechanical Engineering, Southern Taiwan University, Yung-Kang, Taiwan. (2007).

[10] J.Y. Shieh, L.K. Wang, S.Y. Ke, A feasible injection molding technique for the manufacturing of large diameter aspheric plastic lenses, Optical Review. 17 (2010) 399–403.

DOI: 10.1007/s10043-010-0074-8

[11] S.C. Chen, P.S. Minh, S.W. Huang, Y.C. Chiou, Effect of processing parameters on pulse cooling efficiency in injection molding, Antec (2010) 761-764.
