Modeling of Stress in Drills with Curved Cutting Edges

Abstract:

In this paper, it is presented an analysis of the strains and deformation state for a new constructive type of cutting tool the helical drill with three curved cutting edges. The analysis was developed in the application Ansys Workbench, after a definition of the drills geometry in the CATIA environment. It was modeled a specifically load, according to the geometry of the variable working angle of the new drill type. They are presented numerical examples, in comparison with a standard drill, for the diameter of 20 mm.

• Periodical: Applied Mechanics and Materials (Volume 371)
• Pages: 509-513
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.371.509
• Online since: August 2013
• Authors: Nicuşor Baroiu, Doina Boazu, Cosmin Alexandru Vasilache, Virgil Teodor
• Keywords: Deformation, FEM Analysis, Helical Drill with Curved Cutting Edges, Strain

References

[1] E. Abele, M. Fujara, D. Schäfer, Holistic approach for a simulation-based twist drill geometry optimization, International Manufacturing Science and Engineering Conference - MSEC, (2011) 1-9.

DOI: 10.1115/msec2011-50102

[2] W.R. Chen, Parametric studies on buckling loads and critical speeds of microdrill bits, International Journal of Mechanical Sciences, 49 (2007) 935–949.

DOI: 10.1016/j.ijmecsci.2007.01.005

[3] B.K. Hinds, G.M. Treanor, Analysis of stresses in micro-drills using the finite element method, International Journal of Machine Tools & Manufacture, 40 (2000) 1443–1456.

DOI: 10.1016/s0890-6955(00)00007-9

[4] O. Isbilir, E. Ghassemieh, Finite element analysis of drilling of titanium alloy, Procedia Engineering, 10 (2011) 1877–1882.

DOI: 10.1016/j.proeng.2011.04.312

[5] R. Li, A. Shih, Finite element modeling of high-throughput drilling of Ti-6Al-4V, Proceedings of NAMRI/SME, 35 (2007) 73–80.

[6] V. Petrariu, D. Amarandei, S. Alaci, Study about finite element analysis of high speed drilling, Annals of the Oradea University, Fascicle of Management and Technological Engineering, VII (2008) 1684-1689.

[7] C. Constantin, S.M. Croitoru, G. Constantin, C.F. Bisu, 3D FEM analysis of cutting processes, Proceedings of the 3rd WSEAS International Conference on Visualization, Imaging and Simulation, (2010) 41-46.

[8] T.D. Marusich, S. Usui, J. Ma, D.A. Stephenson, A. Shih, Finite element modeling of drilling processes with solid and indexable tooling in metals and stack-ups, 10th CIRP International Workshop on Modeling of Machining Operations, Reggio Calabria, Italy, (2007).

DOI: 10.4028/www.scientific.net/amr.223.182

[9] P. Yongchen, T. Qingchang, Y. Zhaojun, A study of dynamic stresses in micro-drills under high-speed machining, International Journal of Machine Tools & Manufacture, 46 (2006) 1892–(1900).

DOI: 10.1016/j.ijmachtools.2005.10.017

[10] ** Verification Manual for Workbench, Release 12. 1, ANSYS, Inc., Southpointe 275 Technology Drive, (2009).

[11] N. Baroiu, S. Berbinschi, V. Teodor, N. Oancea, Comparative study of drill's flank geometry developed with the Catia software, The Annals of Dunărea de Jos, University of Galati, Fascicle V, 1 (2012) 27-32.

DOI: 10.35219/annugalshipbuilding.2018.41.17

[12] N. Baroiu, S. Berbinschi, V. Teodor, N. Oancea, The modeling of the active surfaces of a multi-flute helical drill with curved cutting edge using the SV& Toolbox environment, Proceedings of the 13th International Conference on Tools – ICT, Miskolc, (2012).

[13] C. Fetecău, F. Stan, N. Oancea, Toroidal grinding method for curved cutting edge twist drills, Journal of Materials Processing Tehnology, 209 (2009) 3460-3468.

DOI: 10.1016/j.jmatprotec.2008.08.003

[14] B.K. Sarkar, Strength of materials, Tata McGraw-Hill Publishing, New Delhi, (2003).
