Fault Tolerant Scheme of Switched Reluctance Machines for the Electro-Mechanical Actuation Systems

Abstract:

As switched reluctance machines (SRM) generally offer a simple and robust design, they are very suitable for electromechanical actuation systems which need to be actuated by fault tolerant drives. This paper investigates dual-channel, dual-redundancy, lacking phase schemes of SRM guaranteeing fault tolerance and the corresponding control systems in detail are compared to point out the advantages and disadvantages of them., a new lacking phase scheme for 12/8 SRM is proposed and the finite element model based on field-circuit coupling is established, results indicate that this scheme have superior fault tolerant performance and suit tasks in electro-mechanical actuation system of aerospace environments.

• Periodical: Applied Mechanics and Materials (Volume 372)
• Pages: 608-611
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.372.608
• Online since: August 2013
• Authors: Xiao Yuan Chen
• Keywords: Electromechanical Actuation System, Fault Tolerant, Switched Reluctance Machine

References

[1] Krishnan R, Blanding D, Bhanot A, et al. High Reliability SRM Drive System for Aerospace Applications[C]. IECON Proceedings (Industrial Electronics Conference), 2003: 1110-1115.

DOI: 10.1109/iecon.2003.1280202

[2] Mecrow B. C, JackA. G, Atkinson D. J, et al. The Design of Fault Tolerant Machines for Aerospace Applications[C] 2005 IEEE International Conference on Electric Machines and Drives, 2005: 1863-1869.

DOI: 10.1109/iemdc.2005.195974

[3] Elbuluk M E. Potential starter/generator technologies for future aerospace application[J]. IEEE Aerospace and Electronic Systems Magazine, 1996, 11(10): 17-24.

DOI: 10.1109/62.538797

[4] Gerling D, Schramm A. Analytical Comparison of Two Different Redundancy Concepts for Switched Reluctance Machines[C]. IEEE International Conference on Industrial Technology, 2006: 871-876.

DOI: 10.1109/icit.2005.1600758

[5] Radun A V, Ferreira C, Richter E. Two-channel switched reluctance starter/generator results[J]. IEEE Transactions on Industry Applications, 1998, 34(5): 1026-1034.

DOI: 10.1109/28.720442

[6] Sanchez J A, Andrada P, Blanque B, Torrent M, et al. Post-fault performance of a fault-tolerant switched reluctance motor drive[C]. IEEE 11th European Conference on Power Electronics and Applications, 2005: 1-8.

DOI: 10.1109/epe.2005.219561
