Control System of Permanent Magnet Synchronous Motor of the Treadmill

Abstract:

According to the characteristics of pulse-load torque of the treadmill, the key technical problems of drive control system in the treadmill with a permanent magnet synchronous motor (PMSM for short) are analyzed. The internal disturbance and external disturbance in the system are observed using the extended state observe (ESO for short) and the system is compensated using the auto-disturbance rejection controller (ADRC for short). The simulation results show that ADRC has better dynamic performance and better robustness to the load disturbance and the motor parameter variation.

• Periodical: Applied Mechanics and Materials (Volumes 373-375)
• Pages: 1389-1392
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.373-375.1389
• Online since: August 2013
• Authors: Hong Nian Chen
• Keywords: ADRC, ESO, Three-Phase AC-PMSM

References

[1] Qingding Guo, Chenyuan Wang: AC Servo System (Machinery Industry Press, Beijing 1994). (In Chinese).

[2] Yi Huang, Jingqing Han: Control Theory and Applications. Vol. 4 (2002), p.485. (In Chinese).

[3] Jingqing Han, Wenge Zhang: Control and Decision. Vol. 4 (1997), p.354. (In Chinese).

[4] Jingqing Han: Acta Automatica Sinica. Vol. 4 (1994), p.487. (In Chinese).

[5] Jingqing Han, Rong Zhang: Journal of System Science and Mathematical Science. Vol. 4 (1999), p.465. (In Chinese).

[6] Guang Feng, Lipei Huang, Dongqing Zhu: Preceeding of the CSEE. Vol. 10 (2001), p.55. ( In Chinese).

[7] Ling Yang, Tiecai Li, Guijie Yang: Electric machines and control. Vol. 1 (2004), p.19. (In Chinese).
