Control System of Pose Error Compensation for Roadheader Based on Multiple Parameter and Negative Feedback

Abstract:

To eliminate the effects for section automatic cutting because of roadheader pose error, Control system of pose error compensation for roadheader was proposed. First, make the control strategy according to the coal mine actual working condition and the working ability of machine each actuator; Hardware system structure is proposed based on the control system and the corresponding sensors are installed; Last, according to the working way of roadheader, put forward the specific control methods of pitch attitude compensation control and cutting boundary compensation control. The above system has been tested on EBZ200 type roadheader and the testing results show that the system function is correct and reliable and the control precision is high. This system could eliminate the effects for section automatic cutting because of roadheader pose error efficiently and lays a foundation for remote control of roadheaders.

• Periodical: Applied Mechanics and Materials (Volumes 373-375)
• Pages: 1551-1558
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.373-375.1551
• Online since: August 2013
• Authors: Yi Bo Du, Wei Zhen Zhang, Su Yu Wang, Xi Gao Liu, Miao Wu
• Keywords: Boom-Type Roadheader, Compensation Control, Directional Tunneling, Negative Feedback, Pose Error

References

[1] Wang LuSheng, Meng Guoying, Tian Jie and so on. Development Status and Trend of Boom-type Roadheader[J]. Coal Mine Machinery, 2007, 28(6): 1-2.

[2] Wang Xuecheng, Zhang Weiguo, Liu Yinglin. Initial Analysis on Present State and Recent Advance of Roadheader[J]. Coal Mine Machinery, 2010, 31(8): 1-3.

[3] Ning Zhongliang and Zhang Shiyong, Automatic Forming Control of Boom-type Roadheaders[J]. Colliery Mechanical & Electrical Technology, 2004(1): 10-11, 15.

[4] Tian Jie, Yang Yang, Chen Guoqiang and so on. Automatic section cutting and forming control of longitudinal-axial-roadheaders[J]. Journal of China Coal Society, 2009, 34(1): 111-115.

[5] Zhang Shiyong. Research on Boom-type roadheader auto profiling control[J]. Journal of Shaanxi University of Technology, 2005, 21(3): 18~20, 27.

[6] Wang suyu, Gao feng, Gao juan and so on. Research on Automatic Cross Section Cutting and Forming Control in Coal Mine Underground Based on Oil Cylinder Stroke Sensor and PCC Electrical Control System[J]. Industry and mine automation, 2012(02).

DOI: 10.1115/1.859896.paper66

[7] Zhu Xinping, Li Rui, Du Yibo and so on. The Measuring Method of Pose Error for roadheader Based on the Total Station[J]. Coal Engineering, 2011, (04): 113-115.

[8] China University of Mining and Technology (Beijing), Shijiazhuang Coal Mine Machinery Co Ltd, Pose parameters measurement system and method for Roadheader, CN101629807 [P] China, Jan (2010).

[9] Li Rui, Zhu Xin-Ping, Gao Juan. Study on Principle and Technology of Position and Attitude Parameters Measurement System for Roadheader[Z]. MACE2011. Hohhot, China.

DOI: 10.1109/mace.2011.5988189

[10] Du Yibo, Mu Jing, Li Rui and so on. Research on the Pose Error Elimination Control Method for Boom-type Roadheader[J]. Industry and mine automation, 2012(02).

DOI: 10.1109/mace.2011.5988161

[11] Mu Jing, Du Yibo, Wu Miao and so on. Analysis of Extreme Position of Cutting Section of Boom-type Roadheader[J]. Industry and Mine Automation, 2011(10): 67-69.

DOI: 10.1109/mace.2011.5988161
