Analysis of Illumination Nonuniformity in Optical Imaging System

Abstract:

In order to study the influence by non-uniformity of illumination on testing performance of optical measurement system, the causes of non-uniformity were analyzed. We constructed the relationship model between interval distance of LED light source and illumination. The distribution of illumination with different intervals of LED were simulated. Then relationship model between viewing-field angle at object plane of optical system and illumination was established. Influence of viewing-field angle at object plane on distribution of illumination was studied. The experimental results indicate that non-uniform light source and wide viewing-field angle are two main causes for non-uniformity in optical imaging system. Larger interval distance of LED or viewing-field angle will result in non-uniformity of illumination.

• Periodical: Applied Mechanics and Materials (Volumes 373-375)
• Pages: 1868-1873
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.373-375.1868
• Online since: August 2013
• Authors: Bin Liu, Li Ming Wang, Xia Zhao
• Keywords: Illumination Non-Uniformity, Light Source, Optical Imaging Detection, View-Field Angle

References

[1] ZHANG Xin，LIN Jia-ming，ZHANG Zhe，et al. Research on measuring technique for image sensors' uniformity of the CCD image-forming system with large-field angle [J]. Optical Technique, 2005, 31(6): 846-853. (in Chinese).

[2] ShenXiangheng, YangLiang, HeGengxianetal. Measurement of image plane illumination non-uniformity of optical system in photoelectric equipment[J] Optics and Precision Engineering., 2008, 16(12): 2513-2536. (in Chinese).

[3] Zhong Xing Zhang Yuan Jin Guang. Illumination Uniformity Optimization of Wide-Viewing-Field Optical System[J] ACTA OPTICA SINACA ，2012, 32(3) (in Chinese).

DOI: 10.3788/aos201232.0322004

[4] XU Xing sheng, MING Hai, ZHAO Xin, et al. On-Line Detection of White Light Illuminated Polymer Optic Fiber with CCD Projection Imaging[J]Opto-ElectronicEngineering, 2000, 27(3): 34-38(in Chinese).

[5] Hailei Hu. Design of LED Illumination System and Research of Illuminance Distribution of LED Arrays [D]. Fujian Normal University. 2005. (in Chinese).

[6] Pu Zhaobang; Qu Yufu; Wang Yaai. Study of IIlumination in Vision Measuring System, Chinese Journal of Scientific Instrument 2003, 24 (4) ：438-439. (in Chinese).

[7] YAN Ping, LI Jian-qing. Computer Aid Design of Optical System of LED for Illumination[J]. SemiconductorOptoelectronics. 2004, 25(3): 181-183. (in Chinese).

[8] Gyeong-il Kweon. Fisheye lens for image processing applications[J]. J. Opt. Soc. Korea, 2008, 12(2): 79-87.
