Development of the Novel Embedded Planetary-Screw Extruder

Abstract:

The novel second-generation embedded planetary-screw extruder prototype was successfully developed in the paper which had eight small planetary-screws and had the excellent degassing function. The numerical simulation of the three-dimensional flow and mixing in the metering zone was carried out for different screw configurations to determine the effect of the number of the small planetary-screws using CFD finite volume method technology. We improved the screw combination of the second-generation prototype according to the simulation results as well as the experimental investigations on first-generation embedded planetary-screw extruder we developed some years ago. The second-generation prototype can effectively improve the axial transport capacity and increase output of the extruder when compared with the first-generation prototype. The novel second-generation prototype can expand the scope of application and can improve the quality of processing material. The novel embedded planetary-screw extruders have a better application prospect.

• Periodical: Applied Mechanics and Materials (Volumes 373-375)
• Pages: 2092-2097
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.373-375.2092
• Online since: August 2013
• Authors: Liang He, Bai Ping Xu, Hui Wen Yu, Xiao Long Wang, Gang Xue
• Keywords: Chaotic Mixing, Embedded Planetary-Screw Extruder, Numerical Simulation

References

[1] Qu Jinping: Engineering Plastics Application, Vol. 83-11 (2000), p.11.

[2] C. Rauwendaal: Plastics Additives and Compounding, Vol. 4-6 (2002), p.24.

[3] PAN Long, ZHANG Yu-xia, JIN Zhi-ming and XUE Ping: China Plastics. Vol. 23-5 (2009), p.12.

[4] Jana.S. C, Tjahjadi. M and OttinoJ.M. AIChEJ, Vol. 94 (1994), p.1769.

[5] Tjahjadi. M, Foster R.W. U.S. Patent 5, 551, 777(1996).

[6] Kim,S. J, Kwon,T. H: Advances in Polymer Technology. Vol. 15-1 (1996), p.41.

[7] Hwang,W. R, Jun,S. H and Kwon,T. H: AIChEJ. Vol. 48-8 (2002), p.1621.

[8] Xu Baiping, Song Jian, Peng Xiangfang, et al. Polymer Materials Science & Engineering. Vol. 24-12 (2008), p.34.

[9] Xu Baiping, Yu Huiwen, He Liang, et al. Journal of Mechanical Engineering. Vol. 48-14 (2012), p.70.

[10] Xu Baiping, Qu Jinping: China Patent ZL200510101486. 9 (2005).

[11] Xu Baiping, Wang Meigui, He Liang and Chen Jinwei: China Patent CN201010140844. 8 (2010).

[12] Wang Meigui, Xu Baiping, Kong Ping, He Liang and Chen Jinwei: Modern Plastics Processing and Applications, Vol. 22-4 (2010), p.57.

[13] Xiaolong Wang, Baiping Xu, Yuejun Liu, et al: Polymer Materials Science & Engineering, Vol. 28-7 (2012), p.171.

[14] Xu Baiping, Wang Xiaolong, Li Jianggang, Chen Jinwei and Liu Yuejun: Journal of Guangdong Industry Technical College. Vol. 10-4(2011), p.6.
