The Simulation of the Interaction between SCR and Seabed

Abstract:

The simulation of the interaction between steel caternary risers (SCRs) and seabed was studied based on beam on elastic foundation theory and the node-spring system foundation mehod for comparison, with the SCR modeled by extensible flexibility cable curve beam. Not only the bottom support and the friction forces were taken into account, but also the damping force of seabed was included in the model of the interaction between SCR and seabed. The results show that compared with using the node-spring system foundation, the effect of the element length of the model on analytical result is insignificant and a longer element could be used for the model, when the beam on elastic foundation model is used. So, the analysis is not time-consuming and the memory requirement is not so large by using the beam on elastic foundation model.

• Periodical: Applied Mechanics and Materials (Volume 378)
• Pages: 102-108
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.378.102
• Online since: August 2013
• Authors: Chao Fan Yang, Wei Ping Huang, Xing Lan Bai, Qing Fei Meng
• Keywords: Beam on Elastic Foundation, Curve Beam with Large Deformation, Deepwater Risers, SCR

References

[1] Y. Bai and Q Bai: Subsea Pipelines and Risers(Elsevier Science Ltd, 2005).

[2] Subrata K. and Chakrabarti: Handbook of Offshore Engineering(Elsevier Science Ltd, 2005).

[3] N.R. T Willis and P.T. J West: Interaction between Deepwater Catenary Risers and a Soft Seabed: Large Scale Sea Trials, Proceedings-Offshore Technology Conference, OTC, Vol. 2, 489-497(2001).

DOI: 10.4043/13113-ms

[4] B. J Leira, E. Passano, D. Karunakaran, K.A. Farnes and E. Giertsen: Analysis Guidelines and Application of a Riser-Soil Interaction Model Including Trench Effects, Proceedings of the International Conference on Offshore Mechanics and Arctic Engineering, ASME (2004).

DOI: 10.1115/omae2004-51527

[5] C.P. Pesce and C.A. Martins Riser-Soil Interaction: Local Dynamics at TDP and a Discussion on the Eigenvalue Problem, Proceedings of the International Conference on Offshore Mechanics and Arctic Engineering, ASME (2004), pp.583-594.

DOI: 10.1115/omae2004-51268

[6] Anon: SCR Seabed Interaction Experiments. Journal of Offshore Technology Vol 12(3) (2004), pp.23-37.

[7] P. Charles, Aubeny, G. Biscontin and J. Zhang: Seafloor Interaction with Steel Catenary Risers. College Station: Texas A&M University, (2006).

[8] W.P. Huang and X.L. Bai: The Simulation of steel catenary risers in deepwater with flexible cable model, Engineering Mechanics, Vol 26(11) (2009), pp.228-231.

[9] 2H Offshore Engineering Ltd: STRIDE JIP-Pull out resistance of a pipe in a clay soil, 2H Offshore Engineering Ltd, (2002).
