Casting Die Designing for Drive Cover

Abstract:

The driving covers casting with complex shape belongs to irregular casting. According to the requirements of size and performance of the thin-walled castings, the expanding-type runner of the trapezoid shape section was adopted, conducive to the production of thin-walled castings. The parting surfaces of the die-casting die are the interface of the movable die and fixed die and that of left and right slider. The left and right slider would be reset by spring. Proved by actual production, the mold operated smoothly, without clamping stagnation, and the production of die castings meet delivery requirements.
