Casting Mold Designing for Aluminum Alloy Car Holders

Abstract:

The structure and processing of car holders castings were analyzed. Die-casting molding process scheme was established. The design of mold includes three core-drawing mechanisms. the gate of the gating system was arranged on the casting bottom surface. For economy and die easy maintenance considerations, die-casting machine, mold, and mold standard parts should be standard parts. The designs of mold gating system and non-standard pieces were completed with the aid of PROE. Proved by actual production, the mold operated smoothly, without clamping stagnation, and the production of die castings meet delivery requirements.
