Design of the Pixel and Row Driving Circuits Using IGZO TFT for QVGA AMOLED

Abstract:

An Amorphous IGZO (a-IGZO) TFTs pixel driving circuit and row driving circuit for AMOLED are proposed. The pixel driving circuit is composed of four a-IGZO TFTs and one capacitor (4T-1C), which effectively compensates the threshold-voltage-shift (ΔV_th1V) of the drive TFT, and shift registers, NAND gates and inverters constitute the row driving circuit. To verify the effect of the proposed circuit, simulation using H-spice was performed, and results prove that the presented circuit can be applied to monochromatic 2-inches QVGA AMOLED.

• Periodical: Applied Mechanics and Materials (Volumes 380-384)
• Pages: 3073-3076
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.380-384.3073
• Online since: August 2013
• Authors: Chun Cheng Yang, Xin Chen, Jian Zhang, Chuan Nan Li
• Keywords: A-IGZO-TFT, Pixel Circuit, Shift Register, Threshold-Voltage-Shift

References

[1] C. W. Tang, An overview of organic electro-luminescent materials and device, J. Soc. Inf. Disp. Vol. 5, no. 1, p.11–14, Mar (1997).

[2] Urabe Tetsuo, The outstanding potential of OLED displays for TV applications, Inf. Disp. Vol. 24, no. 9, p.14–17, Sept (2008).

[3] Juhn Suk Yoo, Hojin Lee, Jerzy Kanicki, Chang-Dong Kim, In-Jae Chung, Novel a-Si: H TFT pixel circuit for electrically stable top-anode light-emitting AMOLEDs, J. Soc. Inf. Disp. Vol. 15, no. 8, p.545–551, Aug (2007).

DOI: 10.1889/1.2770853

[4] Kenji Nomura, Hiromichi Ohta, Akihiro Takagi, Toshio Kamiya, Masahiro Hirano and Hideo Hosono, Room-temperature fabrication of transparent flexible thin-film transistors using amorphous oxide semiconductors, Nature 432, pp.488-492, Nov (2004).

DOI: 10.1038/nature03090

[5] Toshio Kamiya, Kenji Nomura and Hideo Hosono, Present status of amorphous In-Ga-Zn-O thin-film transistors, Sci. Technol. Adv. Mater. Vol. 11, no. 4, 044305 (23pp), Aug (2010).

DOI: 10.1088/1468-6996/11/4/044305

[6] Tze-Ching Fung Katsumi Abe, Hideya Kumomi and Jerzy Kanicki, DC/AC Electrical Instability of R.F. Sputter Amorphous In-Ga-Zn-O TFTs, SID Symp. Dig. Tech., vol. 40, no. 1, p.1117–1120, Jun (2009).

DOI: 10.1889/1.3256481

[7] Charlene Chen, Katsumi Abe and Hideya Kumomi and Jerzy Kanicki, a-InGaZnO thin-film transistors for AMOLEDs: Electrical stability and pixel-circuit simulation. J. Soc. Inf. Disp. Vol. 17, no. 6, p.525–534 , Jun (2009).

DOI: 10.1889/jsid17.6.525

[8] Charlene Chen, Katsumi Abe, Tze-Ching Fung, Hideya Kumomi and Jerzy Kanicki, Amorphous In-Ga-Zn-O Thin Film Transistor Current-Scaling Pixel Electrode Circuit for Active-Matrix Organic Light-Emitting Displays, Jpn. J. Appl. Phys. Vol. 48, 03B025 (7pp) Mar (2009).

DOI: 10.1143/jjap.48.03b025

[9] Michael S. Shur, Holly C. Slade, Mark D. Jacunski, Albert A. Owusu and Trond Ytterdal, SPICE Models for Amorphous Silicon and Polysilicon Thin Film Transistors, J. Electrochem. Soc., vol. 144, no. 8, pp.2833-2839, Aug (1997).

DOI: 10.1149/1.1837903

[10] Y. Toyota, M. Matsumura, M. Hatano, T. Shiba, M. Ohkura, A new study on the degradation mechanism in low-temperature p-channel polycrystalline silicon TFTs under dynamic stress, IEEE Trans. Electron Devices, vol. 53, no. 9, p.2280–2286, Sept (2006).

DOI: 10.1109/ted.2006.879680
