An Identification Method of Harmonic Source in the Power System Based on Independent Component Analysis

Abstract:

In this research, an identification method of harmonic source, based on independent component analysis, was proposed. An unknown harmonic source in the equivalent circuit of power system was regarded as the signal source in the independent component analysis. The known voltage and current of PCC were taken as observed quantities. The independent component analysis and the optimization algorithm were utilized to construct a matrix that could linearly transform voltage and current of PCC into mutually independent signal sources. The harmonic impedance and harmonic source of both the user side and system side were obtained. Then the contribution of users to the harmonic distortion at PCC could be identified. With a good anti-jamming property, this algorithm only needs a condition that variations in the harmonic voltage sources at system side and user side are independent to each other. Simulation results indicated the effectiveness of the method to identify the harmonic source of PCC.

• Periodical: Applied Mechanics and Materials (Volumes 380-384)
• Pages: 4088-4093
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.380-384.4088
• Online since: August 2013
• Authors: Shan Jiang, Min You Chen, Hao Lin, Zhi Sheng Lv, Ang Fu
• Keywords: Harmonic Source Identification, Independent Component Analysis (ICA), Power Quality (PQ)

References

[1] Moussa, Abdel Monem, El-Gammal, Mahmoud A., El-Soud, Ahmed Abou. Determination of harmonic pollution sources in distribution networks through simple measurements- AEJ - Alexandria Engineering Journal. v 38, n 2, p B27-B35, Mar, (1999).

[2] WiIsun Xu. Power Direction Method Cannot Be Used for Harmonic Source Detection [journal article]- Proceedings of the IEEE Power Engineering Society Transmission and Distribution Conference, v2, pp.873-876, (2000).

DOI: 10.1109/pess.2000.867472

[3] Yong Zhao, Jianhua Li, Daozhi Xia. Harmonic source identification and current separation in distribution system. International Journal of Electrical Power & Energy Systems.  26 (1) Jan, 2004, 1-7.

DOI: 10.1016/s0142-0615(03)00065-6

[4] Li Zhinong, Fan Tao, Yue Xiuting. The comparison of traditional independent component analysis with variational Bayesian independent component analysis. Jiangsu University Journal (Natural Science Edition). 2010, 31 (1).

[5] Huang Tianyun. The progress of constrained optimization pattern search method. Journal of computers. 31 (7), July, (2008).

[6] ZhangWei, Yang Honggeng. The estimation method based on harmonic emission level of the binary regression - Electrical Engineering, 24 (6), June, (2004).
