Numerical Simulation of the Thermal Behavior during Laser Metal Deposition Shaping Technology

Abstract:

Laser Metal Deposition Shaping (LMDS) is an emerging manufacturing technique that ensures significant reduction of process time between initial design and final components. The fabrication of fully dense parts with appropriate properties using the LMDS process requires an in-depth understanding of the entire thermal behavior of the process. In this paper, the thermal behavior during LMDS was studied, both numerically and experimentally. Temperature distribution and gradient in the fabricated part were obtained by finite element method (FEM) simulation. The numerical results are in good agreement with the experimental observations. The numerical method contributes to the comprehension and control of the thermal behavior, and may be used to optimize process parameters and predict the thermal response of LMDS fabricated components.

• Periodical: Applied Mechanics and Materials (Volumes 380-384)
• Pages: 4327-4331
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.380-384.4327
• Online since: August 2013
• Authors: Kai Zhang, Lei Wang, Xin Min Zhang
• Keywords: Finite Element Analysis (FEA), Laser Metal Deposition Shaping (LMDS), Temperature Field, Thermal Behavior

References

[1] Li Peng, Yang Taiping, Li Sheng, Liu Dongsheng, Hu Qianwu, Xiong Weihao, et al: Direct Laser Fabrication of Nickel Alloy Samples, International Journal of Machine Tools & Manufacture Vol. 45 (2005), pp.1288-1294.

DOI: 10.1016/j.ijmachtools.2005.01.014

[2] Guang Yang, Wei Wang, Weijun Liu and Lanyun Qin: Laser In-Situ Synthesized TiC Reinforced Titanium Based Wear-Resistant Coating and Its Tribological Performance, Journal of Shenyang University of Technology, Vol. 33(3) (2011).

[3] J. Mazumder: A Crystal Ball View of Direct Metal Deposition, Journal of the Minerals Metals and Materials Society Vol. 52 (2000), pp.28-29.

[4] Peckner, D. and Bernstein, I. M., in: Handbook of Stainless Steels, McGraw-Hill, NewYork, U.S. (1977), pp.19-3, 19-7, 21-5 and 21-6.

[5] Vasinonta, A., Beuth, J. L. and Griffith, M. L.: Process Map for Laser Deposition of Thin-Walled Structures, Solid Freeform Fabrication Proceedings, The University of Texas, Austin, U.S. (1999), pp.383-391.

DOI: 10.1115/1.1370497

[6] Vasinonta, A., Beuth, J. L. and Griffith, M. L.: A Process Map for Consistent Build Conditions in the Solid Freeform Fabrication of Thin-Walled Structures, Journal of Manufacturing Science and Engineering Vol. 123 (2001), pp.615-622.

DOI: 10.1115/1.1370497

[7] Vasinonta, A.: Process Maps for Melt Pool Size and Residual Stress in Laser-based Solid Freeform Fabrication, Ph.D. Thesis, Carnegie Mellon University, Pittsburgh, U.S. (2002).
