A Novel Vehicle Ranging Method Based on Self-Calibration Principle

Abstract:

A novel ranging method based on self-calibration principle is proposed in the paper. This method can be used in vehicle ranging to achieve accurate distance measurement. The principle of the method, hardware architecture and experiment analysis are introduced. Self-calibration principle can eliminate the impact of the velocity of ultrasound on vehicle ranging. Plenty of experiments have been done to validate the design. Both theoretical analysis and experimental results show the effectiveness of the method. A full description of the method and implementation are presented.

• Periodical: Applied Mechanics and Materials (Volumes 380-384)
• Pages: 532-535
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.380-384.532
• Online since: August 2013
• Authors: Zhan Wei Xu, Gui Lin Zheng
• Keywords: NEC Microcomputer, Self-Calibration Principle, Ultrasound (US), Vehicle Ranging

References

[1] Kodama, T., Nakahira, K.: Performance analysis of ultrasonic ranging using a digital polarity correlator. Measurement Science and Technology, 2013, 24(1), P: 1271-1275.

DOI: 10.1088/0957-0233/24/1/015101

[2] K Nakahira1, T Kodama2, T Furuhashi2 and S Okuma1: A self-adapting sonar ranging system based on digital polarity correlators. Instrumentation and measurement, 2004, 15(2), P: 347-352.

DOI: 10.1088/0957-0233/15/2/005

[3] Zhang, Y., Uchida, N., Uematsu, K., Hotta, T., Nakahira, K., Naito, M. : A direct examination of the fracture strength-defect size relationship in alumina ceramics. Key Engineering Materials, 1999, v159-160, P: 269-274.

DOI: 10.4028/www.scientific.net/kem.159-160.269

[4] Hotta, T., Nakahira, K., Naito, M., Shinohara, N., Okumiya, M., Uematsu, K.: Origin of strength change in ceramics associated with the alteration of spray dryer. Journal of Materials Research, 1999 , 14(7), P: 2974-2979.

DOI: 10.1557/jmr.1999.0398

[5] Li, Feng-Chen; Chen, Wen-Li; Li, Hui; Zhang, Rui : An ultrasonic transmission thickness measurement system for study of water rivulets characteristics of stay cables suffering from wind-rain-induced vibration. Sensors and Actuators, A: Physical, 2010 v159(1), P: 12-23.

DOI: 10.1016/j.sna.2010.01.036

[6] Ono, S., Nakahira, K., Tsujioka, S., Uno, N.: Energy absorption capacity of thermally sprayed aluminum friction dampers . Journal of Thermal Spray Technology, 1996, 5(3), P: 303-309.

DOI: 10.1007/bf02645882

[7] Yingfang Fan, Zhiqiang Hu, Jianglin Liu: Application of ultrasonic wave technology to evaluate the corrosion depth of concrete in acid rain environment. Advanced Materials Research, 2010, v129-131, P: 128-133.

DOI: 10.4028/www.scientific.net/amr.129-131.128

[8] NEC, Preliminary User's Manual of 78KOIFC2 (8-Bit Single-Chip Microcontrollers), NEC Electronics Corporation, Japan, (2005).
