Analysis on Influence of Complex Power Transmission Environment on Main Equipment Safety of JiuAn Substation

Abstract:

In the complex power transmission environment, the electromagnetic characteristics of the 500kV JiuAn transformer substation node will change, which will make an important impact on the main equipment of substation. This paper makes in-depth study on the impact of complex power transmission environment on the main equipment, such as high voltage, long-term heavy load, changes of run mode and forced outage. On this basis, PSCAD Software is used to simulate this model, and the simulation result is analyzed. It is significant to ensure the security of main equipment of JiuAn substation.

• Periodical: Applied Mechanics and Materials (Volumes 385-386)
• Pages: 1036-1039
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.385-386.1036
• Online since: August 2013
• Authors: Tian Jiao Pu, Ai Zhong Tian, Zheng Fan, Ye Li, Dan Li
• Keywords: Main Equipment, PSCAD, Substation, UHV

References

[1] Cao Mingde. Discussion on the stable operation of Shanxi grid after UHV commissioning[J]. Shanxi Electric Power, 2010, (02): 24-26.

[2] Xu Zhen, Gao Zhi, and Zhang Changchun. EHV/UHV AC transmission capability analysis. IEEE, Power Engineering Society Winter Meeting. New York: IEEE, 2002(2): 1344-1349.

DOI: 10.1109/pesw.2002.985235

[3] Sun Ke, Yi Qiang, Dong Chaowu, and Zhou Hao. Research on power frequency over-voltage in UHV AC transmission lines[J]. Power System Technology, 2010, (12): 30-35.

[4] Song Lijun, Jiang Taoning, Zou Jun, and Wang Yating. Research on voltages across both terminals of ground wire insulation gap for UHVAC transmission line[J]. Power System Technology, 2013, (03): 686-691.

[5] Li Guangfan, Wang Xiaoning, Li Peng, Sun Lin, and Li Bo, LI Jinzhong. Insulation level and test technology of 1000 kV power transformers[J]. Power System Technology, 2008, (03): 1-6.

DOI: 10.1109/powercon.2010.5666093
